VCO SMT with Fo/2, 6.65 - 7.65 GHz
Key Features
• Dual Output: Fo = 6.65 - 7.65 GHzFo/2 = 3.325 - 3.825 GHz
• Phase Noise:-115 dBc/Hz @100 kHz Typ.
• Pout: +13.5 dBm
• No External Resonator Needed
• QFN Leadless SMT Package, 25 mm2
Description
AI
The HMC507LP5(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCO. The HMC507LP5(E) integrates resonators, negative resistance devices, varactor diodes and feature a half frequency output. The VCO’s phase noise performance is excellent over temperature, shock, and process due to the oscillator’s monolithic structure. Power output is +13.5 dBm typical from a +5V supply. The voltage controlled oscillator is packaged in a leadless QFN 5x5 mm surface mount package, and requires no external matching components.APPLICATIONSVSAT RadioPoint to Point/Multi-Point RadioTest Equipment & Industrial ControlsMilitary End-Use
