C0560 Series
Manufacturer: Prysmian Group
Beta
⌘K
MULTI-PAIR 4COND 18AWG GRAY 500'
| Part | Cable Type | Jacket (Insulation) Material | Wire Gauge | Conductor Insulation | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Number of Conductors | Shield Coverage | Shield Type | Voltage | Length | Length | Usage | Conductor Strand [custom] | Conductor Strand [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Ratings | Jacket Color | Conductor Material | Shield Material | Features | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Prysmian Group | Multi-Pair | Poly-Vinyl Chloride (PVC) | 18 AWG | Poly-Vinyl Chloride (PVC) | 0.042 in | 1.067 mm | 4 | 100 % | Foil | 300 VDC | 152.4 m | 500 ft | Communication Control | 16 | 30 AWG | -20 ░C | 105 ░C | ASTM B-33 | Gray | Copper Annealed Tinned | Copper Flexfoil® Tinned | Drain Wire | 0.314 in | 7.98 mm |
Prysmian Group | Multi-Pair | Poly-Vinyl Chloride (PVC) | 18 AWG | Poly-Vinyl Chloride (PVC) | 0.042 in | 1.067 mm | 4 | Foil | 300 VDC | 152.4 m | 500 ft | Communication Control | 16 | 30 AWG | -20 ░C | 105 ░C | ASTM B-33 | Gray | Copper Annealed Tinned | Drain Wire | 0.314 in | 7.98 mm | ||
 Prysmian Group | Multi-Pair | Poly-Vinyl Chloride (PVC) | 18 AWG | Poly-Vinyl Chloride (PVC) | 0.042 in | 1.067 mm | 4 | 100 % | Foil | 300 VDC | 152.4 m 304.8 m | 500 ft 1000 ft | Communication Control | 16 | 30 AWG | -20 ░C | 105 ░C | ASTM B-33 | Gray | Copper Annealed Tinned | Copper Flexfoil® Tinned | Drain Wire | 0.314 in | 7.98 mm |
