APT11G Series

Catalog

IGBT 1200V 25A 156W TO220

Part	Package / Case	Voltage - Collector Emitter Breakdown (Max) [Max]	IGBT Type	Current - Collector (Ic) (Max) [Max]	Switching Energy	Test Condition	Vce(on) (Max) @ Vge, Ic	Gate Charge	Td (on/off) @ 25°C	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Current - Collector Pulsed (Icm)	Power - Max [Max]	Supplier Device Package	Td (on/off) @ 25°C	Td (on/off) @ 25°C
Microsemi Corporation APT11GF120KRG	TO-220-3	1200 V	NPT	25 A	285 µJ 300 µJ	8 A 10 Ohm 15 V 800 V	3 V	65 nC	7 ns 100 ns	150 °C	-55 °C	Through Hole	44 A	156 W	TO-220 [K]
Microsemi Corporation APT11GF120BRDQ1G	TO-247-3	1200 V	NPT	25 A	285 µJ 300 µJ	8 A 10 Ohm 15 V 800 V	3 V	65 nC	7 ns 100 ns	150 °C	-55 °C	Through Hole		156 W	TO-247 [B]
Microsemi Corporation APT11GP60BDQBG	TO-247-3	600 V	PT	41 A	46 µJ 90 µJ	5 Ohm 11 A 15 V 400 V	2.7 V	40 nC		150 °C	-55 °C	Through Hole	45 A	187 W	TO-247-3	29 ns	7 ns
