896-032 Series
Manufacturer: EDAC Inc.
Catalog
CARD EDGE CONNECTOR, 32 CONTACT(S), 2 ROW(S), FEMALE, RIGHT ANGLE, 0.125 INCH PITCH, SOLDER TERMINAL, HOLE .128, BLACK INSULATOR,
...
| Part | Contact Finish | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row [custom] | Read Out | Color | Pitch [x] | Pitch [x] | Card Type | Termination | Number of Rows | Termination Rows | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Mounting Type | Material - Insulation | Contact Type | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Flange Feature | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 16 | Dual | Black | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Solder | 2 | 2 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole Right Angle | Polyphenylene Sulfide (PPS) | Cantilever | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | |||
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 32 | Single | Black | 0.125 in | 3.18 mm | Non Specified - Single Edge | Solder | 1 | 1 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole Right Angle | Polyphenylene Sulfide (PPS) | Cantilever | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | |||
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 32 | Single | Black | 0.125 in | 3.18 mm | Non Specified - Single Edge | Solder | 1 | 1 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Polyphenylene Sulfide (PPS) | Cantilever | M3 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 32 | Single | Black | 0.125 in | 3.18 mm | Non Specified - Single Edge | Solder | 1 | 1 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Polyphenylene Sulfide (PPS) | Cantilever | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | |||
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 16 | Dual | Black | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Solder | 2 | 2 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole Right Angle | Polyphenylene Sulfide (PPS) | Cantilever | 3.25 mm | 0.128 in | ||||
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 32 | Single | Black | 0.125 in | 3.18 mm | Non Specified - Single Edge | Solder | 1 | 1 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Polyphenylene Sulfide (PPS) | Cantilever | M3 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 32 | Single | Black | 0.125 in | 3.18 mm | Non Specified - Single Edge | Solder | 1 | 1 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Polyphenylene Sulfide (PPS) | Cantilever | 3.96 mm | Top Mount Opening Unthreaded | 0.156 in | |||
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 16 | Dual | Black | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Solder | 2 | 2 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Board Edge Straddle Mount | Polyphenylene Sulfide (PPS) | Cantilever | M3 Threaded Insert Top Mount Opening | Card Extender | ||||
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 32 | Single | Black | 0.125 in | 3.18 mm | Non Specified - Single Edge | Solder | 1 | 1 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Polyphenylene Sulfide (PPS) | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Gold | Copper Alloy | 10 Áin | 0.25 Ám | 16 | Dual | Black | 0.125 in | 3.18 mm | Non Specified - Dual Edge | Solder | 2 | 2 | Female | 125 °C | -40 °C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Polyphenylene Sulfide (PPS) | Cantilever | Side Mount Opening Unthreaded | 3.25 mm | 0.128 in |
