DF13B Series

Catalog

CONN HEADER SMD 5POS 1.25MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish - Mating	Contact Material	Pitch - Mating	Pitch - Mating	Contact Type	Voltage Rating	Insulation Color	Termination	Style	Fastening Type	Connector Type	Shrouding	Material Flammability Rating	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish - Post	Insulation Material	Number of Rows	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Height	Insulation Height	Contact Shape	Number of Positions Loaded	Number of Positions	Features	Mated Stacking Heights	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]
Hirose Electric Co Ltd DF13B-5P-1.25V(76)	0.203 µm	8 µin	Gold	Brass	0.049 in	1.25 mm	Male Pin	150 VDC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C	Gold	Nylon Polyamide (PA)	1	8 µin	0.203 µm	4.8 mm	0.189 in	Square	All	5	Board Guide Solder Retention
Hirose Electric Co Ltd DF13B-8P-1.25V(77)			Gold	Brass	0.049 in	1.25 mm	Male Pin	150 VDC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C		Nylon Polyamide (PA)	1	30 Áin	0.76 Ám	4.8 mm	0.189 in	Square	All	8	Board Guide Solder Retention	5.8 mm
Hirose Electric Co Ltd DF13B-4P-1.25V(75)	1 çm	39.4 çin		Brass	0.049 in	1.25 mm	Male Pin	150 VDC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C	Tin	Nylon Polyamide (PA)	1			4.8 mm	0.189 in	Square	All	4	Board Guide Solder Retention		39.4 µin	1 µm
Hirose Electric Co Ltd DF13B-7P-1.25V(21)	1 çm	39.4 çin		Brass	0.049 in	1.25 mm	Male Pin	150 VAC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C	Tin	Nylon Polyamide (PA)	1			4.8 mm	0.189 in	Square	All	7	Solder Retention		39.4 µin	1 µm
Hirose Electric Co Ltd DF13B-2P-1.25V(75)	1 çm	39.4 çin		Brass	0.049 in	1.25 mm	Male Pin	150 VDC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C	Tin	Nylon Polyamide (PA)	1			4.8 mm	0.189 in	Square	All	2	Board Guide Solder Retention		39.4 µin	1 µm
Hirose Electric Co Ltd DF13B-5P-1.25V(77)			Gold	Brass	0.049 in	1.25 mm	Male Pin	150 VDC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C		Nylon Polyamide (PA)	1	30 Áin	0.76 Ám	4.8 mm	0.189 in	Square	All	5	Board Guide Solder Retention	5.8 mm
Hirose Electric Co Ltd DF13B-4P-1.25V(51)			Gold	Brass	0.049 in	1.25 mm	Male Pin	150 VDC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C		Nylon Polyamide (PA)	1	8 µin	0.203 µm	4.8 mm	0.189 in	Square	All	4	Board Guide Solder Retention	5.8 mm
Hirose Electric Co Ltd DF13B-15P-1.25V(51)			Gold	Brass	0.049 in	1.25 mm	Male Pin	150 VDC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C		Nylon Polyamide (PA)	1	8 µin	0.203 µm	4.8 mm	0.189 in	Square	All	15	Board Guide Solder Retention	5.8 mm
Hirose Electric Co Ltd DF13B-3P-1.25V(50)			Gold	Brass	0.049 in	1.25 mm	Male Pin	150 VDC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C		Nylon Polyamide (PA)	1	8 µin	0.203 µm	4.8 mm	0.189 in	Square	All		Board Guide Solder Retention	5.8 mm
Hirose Electric Co Ltd DF13B-10P-1.25V(75)	1 çm	39.4 çin		Brass	0.049 in	1.25 mm	Male Pin	150 VDC	Beige	Solder	Board to Cable/Wire	Detent Lock	Header	Shrouded - 3 Wall	UL94 V-0	Surface Mount	85 °C	-35 °C	Tin	Nylon Polyamide (PA)	1			4.8 mm	0.189 in	Square	All	10	Board Guide Solder Retention		39.4 µin	1 µm
