BSC011 Series

Manufacturer: INFINEON

Catalog

POWER MOSFET, N CHANNEL, 30 V, 230 A, 900 ΜOHM, TDSON, SURFACE MOUNT

Part	Power Dissipation (Max)	Rds On (Max) @ Id, Vgs	Technology	Vgs(th) (Max) @ Id	Drive Voltage (Max Rds On, Min Rds On)	Mounting Type	Vgs (Max)	Input Capacitance (Ciss) (Max) @ Vds	Package / Case	Gate Charge (Qg) (Max) @ Vgs	Supplier Device Package	Current - Continuous Drain (Id) @ 25°C	Drain to Source Voltage (Vdss)	FET Type	Operating Temperature [Max]	Operating Temperature [Min]	Gate Charge (Qg) (Max) @ Vgs [Max]
INFINEON BSC011N03LSATMA1	2.5 W 96 W	1.1 mOhm	MOSFET (Metal Oxide)	2.2 V	4.5 V 10 V	Surface Mount	20 V	4700 pF	8-PowerTDFN	72 nC	PG-TDSON-8-1	37 A 100 A	30 V	N-Channel	175 °C	-55 °C
INFINEON BSC011N03LSTATMA1	3 W 115 W	1.1 mOhm	MOSFET (Metal Oxide)	2 V	4.5 V 10 V	Surface Mount	20 V	6300 pF	8-PowerTDFN		PG-TDSON-8 FL	39 A 100 A	30 V	N-Channel	175 °C	-55 °C	48 nC
