AM2DM Series
Manufacturer: aimtec
Beta
⌘K
MODULE DC-DC 24VIN 2-OUT -15V/15V -0.067A/0.067A 2W 5-PIN SIP MODULE
| Part | Mounting Type | Current - Output (Max) | Type | Voltage - Input (Min) | Efficiency | Approval Agency | Voltage - Output 2 | Number of Outputs | Voltage - Isolation | Power (Watts) | Applications | Operating Temperature (Min) | Operating Temperature (Max) | Voltage - Output 1 | Size / Dimension Width | Size / Dimension Height | Size / Dimension Length | Voltage - Input (Max) | Package Name | Package Leads | Package / Case | Voltage - Output 1 (Min) | Voltage - Output 1 (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | Through Hole | 67 mA | Isolated Module | 21.6 V | 81 % | CE cURus | -15 V | 2 | 6 kV | 2 w | Medical | -40 °C | 85 °C | 15 V | 0.39 in | 0.49 in | 0.77 in | 26.4 V | 7-SIP | 5 Leads | |||
 aimtec | Through Hole | 167 mA | Isolated Module | 10.8 V | 80 % | CE cURus | 1 | 6 kV | 2 w | Medical | -40 °C | 85 °C | 12 V | 0.39 in | 0.49 in | 0.77 in | 13.2 V | 7-SIP Module | |||||
aimtec | Through Hole | 400 mA | Isolated Module | 4.5 V | 77 % | CE cURus | 1 | 6 kV | 2 w | Medical | -40 °C | 85 °C | 5 V | 0.39 in | 0.51 in | 0.77 in | 5.5 V | 7-SIP Module | 4 Leads | ||||
aimtec | Through Hole | 111 mA | Isolated Module | 21.6 V | 81 % | CE cURus | -9 V | 2 | 6 kV | 2 w | Medical | -40 °C | 85 °C | 0.39 in | 0.51 in | 0.77 in | 26.4 V | 7-SIP | 5 Leads | -9 V | 9 V | ||
 aimtec | Through Hole | 133 mA | Isolated Module | 21.6 V | 84 % | CE cURus | 1 | 6 kV | 2 w | Medical | -40 °C | 85 °C | 15 V | 0.39 in | 0.49 in | 0.77 in | 26.4 V | 7-SIP 7-SIP Module | 4 Leads |
