AMA24 Series

Manufacturer: aimtec

Catalog

AC/DC WALL MOUNT ADAPTER 12V 24W

Part	Weight	Weight	Standard Number	Approval Agency	Cord Length	Cord Length	No Load Power Consumption	Voltage - Output	Region Utilized	Polarization	Power (Watts)	Output Connector	Output Connector [diameter]	Output Connector [x]	Voltage - Input [Max]	Voltage - Input [Min]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Efficiency	Input Type	Current - Output (Max) [Max]	Input Connector	Applications	Operating Temperature [Max]	Form
aimtec AMA24UR4-120200Y	130 g	0.287 lb	60950-1 62368-1	CE FCC UL	1.5 m	60.2 in	100 mW	12 V	North America	Positive Center	24 W	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	264 VAC	90 VAC	2.83 in	34 mm	73 mm	2.87 in	1.34 in	72 mm	Level VI	Fixed Blade	2 A	NEMA 1-15P	ITE (Commercial)	40 °C	Wall Mount
aimtec AMA24UR4-120150Y	130 g	0.287 lb	60950-1 62368-1	CE FCC UL	1.5 m	60.2 in	100 mW	12 V	North America	Positive Center	18 W	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	264 VAC	90 VAC	2.83 in	34 mm	73 mm	2.87 in	1.34 in	72 mm	Level VI	Fixed Blade	1.5 A	NEMA 1-15P	ITE (Commercial)	40 °C	Wall Mount
aimtec AMA24EU2-120200Y	130 g	0.287 lb	60950-1 62368-1	CE IEC UL	1.5 m	59 in	100 mW	12 V	Europe		24 W	USB C			264 VAC	90 VAC	2.83 in	34 mm	88 mm	3.46 in	1.34 in	72 mm	Level VI	Fixed Blade	2 A	CEE 7/16	ITE (Commercial)	40 °C	Wall Mount
aimtec AMA24UR4-050300Y	130 g	0.287 lb	60950-1 62368-1	CE FCC UL	1.5 m	60.2 in	100 mW	5 V	North America	Positive Center	15 W	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	264 VAC	90 VAC	2.83 in	34 mm	73 mm	2.87 in	1.34 in	72 mm	Level VI	Fixed Blade	3 A	NEMA 1-15P	ITE (Commercial)	40 °C	Wall Mount
aimtec AMA24DR4-120150Y	140 g	0.309 lb	62368-1	CE FCC UL	1.5 m	60.2 in	100 mW	12 V	International	Positive Center	18 W	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	264 VAC	90 VAC	3.54 in	50 mm	33.9 mm	1.33 in	1.97 in	90 mm	Level VI	Cord (Sold Separately)	1.5 A	IEC 320-C8	ITE (Commercial)	40 °C	Desktop (Class II)
aimtec AMA24UR5-120200Y	130 g	0.287 lb	60950-1 62368-1	CE FCC UL	1.5 m	60.2 in	100 mW	12 V	North America	Positive Center	24 W	Barrel Plug	2.5 mm 5.5 mm	9.5 mm	264 VAC	90 VAC	2.83 in	34 mm	73 mm	2.87 in	1.34 in	72 mm	Level VI	Fixed Blade	2 A	NEMA 1-15P	ITE (Commercial)	40 °C	Wall Mount
