846-013 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 13POS 0.125
| Part | Material - Insulation | Termination Rows | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Contact Finish | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Pitch | Pitch | Number of Positions | Termination | Contact Type | Gender | Number of Positions/Bay/Row | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Color | Read Out | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Wire Wrap | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Solder | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Wire Wrap | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Solder | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Solder | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Solder | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Floating Bobbin Top Mount Opening | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Solder | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single | 0.116 " | 2.95 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Wire Wrap | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Solder | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | 1 | 3.18 mm | 0.125 in | 13 | Solder Eyelet(s) | Cantilever | Female | 13 | Non Specified - Single Edge | 125 °C | -40 C | Green | Single |
