DF3 Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN SHROUDED HEADER (4 SIDES) HDR 5 POS 2MM SOLDER RA SMD REEL
| Part | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Style | Number of Rows | Insulation Color | Contact Type | Shrouding | Number of Positions Loaded | Pitch - Mating | Pitch - Mating | Features | Contact Finish - Mating | Insulation Height | Insulation Height | Number of Positions | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Material Flammability Rating | Termination | Contact Shape | Fastening Type | Connector Type | Insulation Material | Contact Material | Current Rating (Amps) | Contact Finish Thickness - Post [custom] | Contact Finish Thickness - Post [custom] | Contact Length - Post | Contact Length - Post | Mated Stacking Heights [Min] [z] | Mated Stacking Heights [Max] [z] | Contact Finish - Post | Current Rating (Amps) | Contact Length - Mating | Contact Length - Mating | Contact Length - Post [x] | Contact Length - Post [x] | Overall Contact Length | Accessory Type | For Use With/Related Products |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Right Angle Surface Mount | -55 C | 105 ░C | 250 VAC | Board to Board Cable | 1 | Beige | Male Pin | Shrouded - 4 Wall | All | 0.079 " | 2 mm | Solder Retention | Gold | 5.6 mm | 0.22 in | 5 | 8 µin | 0.203 µm | UL94 V-0 | Solder | Circular | Push-Pull | Header | Nylon Polyamide (PA) | Brass | Varies by Wire Gauge | |||||||||||||||
 Hirose Electric Co Ltd | Through Hole | -30 ░C | 85 °C | 30 VAC | Board to Board Cable | 1 | Black | Female Socket | All | 0.079 " | 2 mm | 5.9 mm | 0.232 in | 11 | 78.7 µin | 2 µm | UL94 V-0 | Solder | Square | Friction Lock | Receptacle | Nylon Polyamide (PA) | Phosphor Bronze | 78.7 µin | 2 µm | 0.118 in | 3 mm | 6.6 mm | 7.5 mm | Tin | 3 A | |||||||||||
 Hirose Electric Co Ltd | Right Angle Through Hole | -55 C | 105 ░C | Board to Board Cable | 1 | Black | Male Pin | Shrouded - 4 Wall | All | 0.079 " | 2 mm | Gold | 5 mm | 0.197 " | 7 | 8 µin | 0.203 µm | UL94 V-0 | Press-Fit Solder | Square | Push-Pull | Header | Nylon Polyamide (PA) | Brass | 3 A | 0.122 in | 3.1 mm | 0.114 in | 2.9 mm | |||||||||||||
 Hirose Electric Co Ltd | Surface Mount | -55 C | 105 ░C | 250 VAC | Board to Board Cable | 1 | Black | Male Pin | Shrouded - 4 Wall | All | 0.079 " | 2 mm | Board Guide Solder Retention | Gold | 5.9 mm | 0.232 in | 6 | 8 µin | 0.203 µm | UL94 V-0 | Solder | Circular | Push-Pull | Header | Nylon Polyamide (PA) | Brass | Varies by Wire Gauge | Gold | ||||||||||||||
 Hirose Electric Co Ltd | Right Angle Through Hole | -55 C | 105 ░C | Board to Board Cable | 1 | Black | Male Pin | Shrouded - 4 Wall | All | 0.079 " | 2 mm | 5 mm | 0.197 " | 8 | UL94 V-0 | Press-Fit Solder | Square | Push-Pull | Header | Nylon Polyamide (PA) | Brass | Tin | 3 A | 0.122 in | 3.1 mm | 0.114 in | 2.9 mm | |||||||||||||||
 Hirose Electric Co Ltd | Right Angle Through Hole | -55 C | 105 ░C | Board to Board Cable | 1 | Black | Male Pin | Shrouded - 4 Wall | All | 0.079 " | 2 mm | Gold | 5 mm | 0.197 " | 8 µin | 0.203 µm | UL94 V-0 | Press-Fit Solder | Square | Push-Pull | Header | Nylon Polyamide (PA) | Brass | 3 A | 0.122 in | 3.1 mm | 0.114 in | 2.9 mm | ||||||||||||||
 Hirose Electric Co Ltd | Through Hole | -55 C | 105 ░C | Board to Board Cable | 1 | Black | Male Pin | Shrouded - 4 Wall | All | 0.079 " | 2 mm | Gold | 5 mm | 0.197 " | 6 | 8 µin | 0.203 µm | UL94 V-0 | Press-Fit Solder | Square | Push-Pull | Header | Nylon Polyamide (PA) | Brass | 3 A | 0.122 in | 3.1 mm | 0.114 in | 2.9 mm | 0.299 in 7.6 mm | ||||||||||||
 Hirose Electric Co Ltd | Right Angle Through Hole | -55 C | 105 ░C | Board to Board Cable | 1 | Black | Male Pin | Shrouded - 4 Wall | All | 0.079 " | 2 mm | 5 mm | 0.197 " | 4 | UL94 V-0 | Press-Fit Solder | Square | Push-Pull | Header | Nylon Polyamide (PA) | Brass | Tin | 3 A | 0.122 in | 3.1 mm | 0.114 in | 2.9 mm | |||||||||||||||
 Hirose Electric Co Ltd | Surface Mount | -55 C | 105 ░C | 250 VAC | Board to Board Cable | 1 | Beige | Male Pin | Shrouded - 4 Wall | All | 0.079 " | 2 mm | Board Guide Solder Retention | Gold | 5.9 mm | 0.232 in | UL94 V-0 | Solder | Circular | Push-Pull | Header | Nylon Polyamide (PA) | Brass | Varies by Wire Gauge | ||||||||||||||||||
 Hirose Electric Co Ltd | Crimp Head Components | DF3-TA22HC |
