1435 Series

Catalog

BOX S STL NATURAL 9.5"L X 6.25"W

Part	Weight	Weight	Height	Height [z]	Thickness	Features	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Ratings	Color	Area (L x W)	Area (L x W)	Container Type	Design	Material	Size / Dimension [y]	Thickness	Height
Hammond Manufacturing 1435SSH	2.7 kg	6 lbs	76.2 mm	3 in	14 Gauge	Pushbutton Holes - 6	158.75 mm	241.3 mm	9.5 in	6.25 in	IP66 JIC EGP-1-1967 NEMA 3R NEMA 4 NEMA 4X UL-508	Natural	383 cm²	59.4 in²	Box	Hinged Door Lid	Metal Stainless Steel
Hammond Manufacturing 1435S16B	1.4 kg	3.1 lbs	69.85 mm			Pushbutton Holes - 2		146.05 mm	5.75 in	3.25 "	IP66 JIC EGP-1-1967 NEMA 3R NEMA 4 NEMA 4X UL-508	Natural	121 cm²	18.7 in²	Box	Cover Included	Metal Stainless Steel	82.55 mm	16 Gauge	2.75 in
Hammond Manufacturing 1435MS	4.5 kg	10 lbs	76.2 mm	3 in	14 Gauge	Pushbutton Holes - 16	273.05 mm	298.45 mm	11.75 in	10.75 in	IP54 JIC EGP-1-1967 NEMA 12 NEMA 13 UL-508	Gray	813 cm²	126 in²	Box	Hinged Door Lid	Metal Steel
Hammond Manufacturing 1435MS16H	2.7 kg	6 lbs	76.2 mm	3 in	14 Gauge	Pushbutton Holes - 6	158.75 mm	241.3 mm	9.5 in	6.25 in	IP66 JIC EGP-1-1967 NEMA 3R NEMA 4 NEMA 4X UL-508	Natural	383 cm²	59.4 in²	Box	Hinged Door Lid	Metal Stainless Steel
Hammond Manufacturing 1435SSB	1.4 kg	3.1 lbs	69.85 mm			Pushbutton Holes - 2		146.05 mm	5.75 in	3.25 "	IP66 JIC EGP-1-1967 NEMA 3R NEMA 4 NEMA 4X UL-508	Natural	121 cm²	18.7 in²	Box	Cover Included	Metal Stainless Steel	82.55 mm	16 Gauge	2.75 in
Hammond Manufacturing 1435MSSC	1.4 kg	3.1 lbs	69.85 mm		14 Gauge		82.55 mm	203.2 mm			IP66 JIC EGP-1-1967 NEMA 3R NEMA 4 NEMA 4X UL-508	Natural	168 cm²	26 in²	Box	Cover Included	Metal Stainless Steel			2.75 in
Hammond Manufacturing 1435MSSO	3.6 kg	8 lbs	76.2 mm	3 in	14 Gauge	Pushbutton Holes - 12		298.45 mm	11.75 in	8.5 in	IP66 JIC EGP-1-1967 NEMA 3R NEMA 4 NEMA 4X UL-508	Natural			Box	Hinged Door Lid	Metal Stainless Steel	215.9 mm
Hammond Manufacturing 1435MS16K	3.2 kg	7 lbs	76.2 mm	3 in	14 Gauge	Pushbutton Holes - 9	215.9 mm	241.3 mm	9.5 in	8.5 in	IP66 JIC EGP-1-1967 NEMA 3R NEMA 4 NEMA 4X UL-508	Natural	521 cm²	80.8 in²	Box	Hinged Door Lid	Metal Stainless Steel
Hammond Manufacturing 1435A	907.2 g	2 lbs	69.85 mm			Pushbutton Holes - 1	82.55 mm	88.9 mm	3.5 "	3.25 "	IP54 JIC EGP-1-1967 NEMA 12 NEMA 13 UL-508	Gray	74 cm²	11.5 in²	Box	Cover Included	Metal Steel		16 Gauge	2.75 in
Hammond Manufacturing 1435MSSH	2.7 kg	6 lbs	76.2 mm	3 in	14 Gauge	Pushbutton Holes - 6	158.75 mm	241.3 mm	9.5 in	6.25 in	IP66 JIC EGP-1-1967 NEMA 3R NEMA 4 NEMA 4X UL-508	Natural	383 cm²	59.4 in²	Box	Hinged Door Lid	Metal Stainless Steel
