H11AV1 Series
Manufacturer: Isocom Components 2004 LTD
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
OPTOISO 5.3KV TRANS W/BASE 6DIP
| Part | Output Type | Voltage - Output (Max) | Vce Saturation (Max) | Package Name | Current Transfer Ratio (Max) | Number of Channels | Mounting Type | Current - DC Forward (If) (Max) | Voltage - Isolation | Voltage - Forward (Vf) (Typ) | Package Length | Package Width | Rise Time (Typ) | Fall Time (Typ) | Current - Output / Channel | Input Type | Current Transfer Ratio (Min) | Operating Temperature (Min) | Operating Temperature (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Isocom Components 2004 LTD | Transistor with Base | 70 V | 400 mV | 6-DIP | 300 % | 1 | Through Hole | 60 mA | 5.3 kV | 1.2 V | 0.3 in | 7.62 mm | 2 µs | 2 µs | 50 mA | DC | 100 % | -55 °C | 100 °C |
