12-823 Series
Manufacturer: Aries Electronics
Beta
⌘K
CONN IC DIP SOCKET 12POS GOLD
| Part | Current Rating (Amps) | Termination Post Length | Termination Post Length | Material Flammability Rating | Number of Positions or Pins (Grid) | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish - Post | Housing Material | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Post | Pitch - Post | Contact Material - Post [custom] | Features | Termination | Type | Type | Type | Pitch - Mating | Pitch - Mating | Contact Finish - Mating | Contact Material - Mating | Contact Finish Thickness - Post | Contact Finish Thickness - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Aries Electronics | 3 A | 3.56 mm | 0.14 in | UL94 V-0 | 12 | 0.76 Ám | 30 Áin | Tin | Polyamide (PA46) Nylon 4/6 Glass Filled | -55 C | 105 ░C | 0.1 in | 2.54 mm | Brass | Closed Frame | Solder | 7.62 mm | 0.3 in | DIP | 0.1 " | 2.54 mm | Gold | Beryllium Copper | 200 µin | 5.08 µm |
