396-078 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 78POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Read Out | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Positions/Bay/Row | Features | Flange Feature | Gender | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Number of Positions | Termination | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Contact Material | Pitch | Pitch | Contact Type | Color | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | Card Extender | Flush Mount M3 Threaded Insert Top Opening | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Solder Eyelet(s) | Board Edge Straddle Mount | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | Card Guides | 4-40 Flush Mount Threaded Insert Top Opening | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Solder Wire Wrap | Right Angle Through Hole | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | Card Guides | 4-40 Threaded Insert Top Mount Opening | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Wire Wrap | Through Hole | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | 4-40 Threaded Insert Top Mount Opening | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Solder Wire Wrap | Right Angle Through Hole | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | 4-40 Threaded Insert Top Mount Opening | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Solder Wire Wrap | Right Angle Through Hole | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Solder | Through Hole | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | Card Extender | Flush Mount M3 Threaded Insert Top Opening | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Solder | Board Edge Straddle Mount | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | Card Extender Card Guides | 4-40 Threaded Insert Top Mount Opening | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Solder | Board Edge Straddle Mount | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | Card Extender | 4-40 Flush Mount Threaded Insert Top Opening | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Solder | Board Edge Straddle Mount | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 39 | Card Guides | 4-40 Threaded Insert Top Mount Opening | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 78 | Solder | Through Hole | -40 C | 105 ░C | Gold | Copper Alloy | 3.18 mm | 0.125 in | Cantilever | Black |
