TEN 12 Series

Catalog

DC DC CONVERTER +/-15V 12W

Part	Power (Watts)	Current - Output (Max)	Voltage - Output 2	Mounting Type	Features	Voltage - Input (Min) [Min]	Size / Dimension	Applications	Voltage - Isolation	Voltage - Input (Max) [Max]	Number of Outputs	Type	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output 1	Efficiency	Package / Case	Current - Output (Max) [Max]
Traco Power TEN 12-4823	12 W	400 mA	-15 V	Through Hole	OCP OVP Remote On/Off SCP	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	ITE (Commercial)	1.5 kV	75 V	2	Isolated Module	-40 °C	85 °C	15 V	84 %	5-DIP Module
Traco Power TEN 12-4810	7.9 W			Through Hole	OCP OVP Remote On/Off SCP	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	ITE (Commercial)	1.5 kV	75 V	1	Isolated Module	-40 °C	85 °C	3.3 V	78 %	5-DIP Module 4 Leads	2.4 A
Traco Power TEN 12-4811	10 W			Through Hole	OCP OVP Remote On/Off SCP	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	ITE (Commercial)	1.5 kV	75 V	1	Isolated Module	-40 °C	85 °C	5 V		5-DIP Module 4 Leads	2 A
Traco Power TEN 12-4822	12 W	500 mA	-12 V	Through Hole	OCP OVP Remote On/Off SCP	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	ITE (Commercial)	1.5 kV	75 V	2	Isolated Module	-40 °C	85 °C	12 V	84 %	5-DIP Module
Traco Power TEN 12-2422	12 W	500 mA	-12 V	Through Hole	OCP OVP Remote On/Off SCP	9 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	ITE (Commercial)	1.5 kV	36 V	2	Isolated Module	-40 °C	85 °C	12 V	84 %	5-DIP Module
Traco Power TEN 12-4821	10 W	1 A	-5 V	Through Hole	OCP OVP Remote On/Off SCP	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	ITE (Commercial)	1.5 kV	75 V	2	Isolated Module	-40 °C	85 °C	5 V		5-DIP Module
