E2522S Series

Catalog

CABLE 2COND 16AWG YELLOW SHLD

Part	Voltage	Wire Gauge	Jacket Color	Length	Length	Ratings	Conductor Strand	Shield Type	Usage	Features	Cable Type	Conductor Material	Conductor Insulation	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Material	Number of Conductors	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Shield Coverage	Shield Material	Length [x]	Length [x]
Prysmian Group E2522S.41.05	300 VDC	16 AWG	Yellow	304.8 m	1000 ft	ASTM B-3	Solid	Foil	Alarm Safety	Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC)	2	4.57 mm	0.18 in
Prysmian Group E2522S.41.01	300 VDC	16 AWG	Black	304.8 m	1000 ft	ASTM B-3	Solid	Foil		Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC) Riser	2	4.57 mm	0.18 in	100 %	Flexfoil®
Prysmian Group E2522S.30.02	300 VDC	16 AWG	White	304.8 m	1000 ft	ASTM B-3	Solid	Foil	Alarm Safety	Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC)	2	4.57 mm	0.18 in	100 %	Flexfoil®
Prysmian Group E2522S.41.03	300 VDC	16 AWG	Red	304.8 m	1000 ft	ASTM B-3	Solid	Foil	Alarm Safety	Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC)	2	4.57 mm	0.18 in	100 %	Flexfoil®
Prysmian Group E2522S.41.07	300 VDC	16 AWG	Blue	304.8 m	1000 ft	ASTM B-3	Solid	Foil	Alarm Safety	Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC)	2	4.57 mm	0.18 in
Prysmian Group E2522S.41.01	300 VDC	16 AWG	Black	304.8 m	1000 ft	ASTM B-3	Solid	Foil		Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC) Riser	2	4.57 mm	0.18 in
Prysmian Group E2522S.30.03	300 VDC	16 AWG	Red	304.8 m	1000 ft	ASTM B-3	Solid	Foil	Alarm Safety	Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC)	2	4.57 mm	0.18 in	100 %	Flexfoil®
Prysmian Group E2522S.30.03	300 VDC	16 AWG	Red	304.8 m	1000 ft	ASTM B-3	Solid	Foil	Alarm Safety	Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC)	2	4.57 mm	0.18 in
Prysmian Group E2522S.41.03	300 VDC	16 AWG	Red	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft	ASTM B-3	Solid	Foil	Alarm Safety	Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC)	2	4.57 mm	0.18 in			100 ft	30.5 m
Prysmian Group E2522S.30.02	300 VDC	16 AWG	White	304.8 m	1000 ft	ASTM B-3	Solid	Foil	Alarm Safety	Drain Wire Rip Cord	Multi-Conductor	Copper Annealed Bare	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	Poly-Vinyl Chloride (PVC)	2	4.57 mm	0.18 in
