833-030 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 30POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions | Read Out | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Color | Card Thickness [Max] | Card Thickness [Min] | Gender | Contact Material | Number of Positions/Bay/Row | Card Type | Termination | Number of Rows | Mounting Type | Termination Rows [custom] | Flange Feature | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 30 | Single | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | 0.156 " | 3.96 mm | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 30 | Non Specified - Single Edge | Wire Wrap | 1 | Through Hole | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | Dual | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 15 | Non Specified - Dual Edge | Solder | Through Hole | 2 | Flush Mount M3 Threaded Insert Top Opening | 2 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 30 | Single | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | 0.116 " | 2.95 mm | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 30 | Non Specified - Single Edge | Wire Wrap | 1 | Through Hole | Floating Bobbin Top Mount Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | Dual | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 15 | Non Specified - Dual Edge | Solder | Through Hole | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | Dual | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 15 | Non Specified - Dual Edge | Solder | Board Edge Straddle Mount | 2 | 2 | Card Extender | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 30 | Single | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 30 | Non Specified - Single Edge | Solder | 1 | Through Hole | 4-40 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 30 | Single | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | 0.128 " | 3.25 mm | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 30 | Non Specified - Single Edge | Solder | 1 | Through Hole | Side Mount Opening Unthreaded | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | Dual | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | 0.156 " | 3.96 mm | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 15 | Non Specified - Dual Edge | Solder | Right Angle Through Hole | 2 | Flush Mount Top Opening Unthreaded | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | Dual | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | 0.128 " | 3.25 mm | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 15 | Non Specified - Dual Edge | Wire Wrap | Through Hole | 2 | Flush Mount Top Opening Unthreaded | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | Dual | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | 0.128 " | 3.25 mm | Gold | 125 °C | -40 C | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Copper Alloy | 15 | Non Specified - Dual Edge | Wire Wrap | Through Hole | 2 | Side Mount Opening Unthreaded | 2 |
