UMW Series

Manufacturer: Nichicon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED 10VOLTS 22UF 85C 5X5 2LS

Part	Size / Dimension [diameter]	Size / Dimension [diameter]	Lifetime @ Temp.	Ripple Current @ Low Frequency	Mounting Type	Voltage - Rated	Package / Case	Capacitance	Applications	Polarization	Operating Temperature [Max]	Operating Temperature [Min]	Tolerance	Lead Spacing	Lead Spacing	Height - Seated (Max)	Height - Seated (Max) [Max]	Ripple Current @ High Frequency
Nichicon UMW1A220MDD	0.197 in	5 mm	1000 Hrs	33 mA	Through Hole	10 V	Can Radial	22 µF	Audio	Polar	85 °C	-40 C	20 %	2 mm	0.079 in	6 mm	0.236 "
Nichicon UMW0J101MDD	0.248 "	6.3 mm	1000 Hrs	70 mA	Through Hole	6.3 VDC	Can Radial	100 µF	Audio	Polar	85 °C	-40 C	20 %	2.5 mm	0.098 in	6 mm	0.236 "	105 mA
Nichicon UMW1H4R7MDD	0.197 in	5 mm	1000 Hrs	20 mA	Through Hole	50 VDC	Can Radial	4.7 µF	Audio	Polar	85 °C	-40 C	20 %	2 mm	0.079 in	6 mm	0.236 "	30 mA
Nichicon UMW0J221MDD	0.315 in	8 mm	1000 Hrs	110 mA	Through Hole	6.3 VDC	Can Radial	220 µF	Audio	Polar	85 °C	-40 C	20 %	2.5 mm	0.098 in	6 mm	0.236 "	165 mA
