AMEL6 Series
Manufacturer: aimtec
Beta
⌘K
AC/DC CONVERTER 15V 6W
| Part | Mounting Type | Type | Current - Output (Max) [Max] | Voltage - Output 1 | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Weight | Weight | Power (Watts) | Line Regulation | Package / Case | Load Regulation | Efficiency | Applications | Features | Voltage - Input [Min] | Voltage - Input [Max] | Number of Outputs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | Through Hole | Enclosed | 400 mA | 15 V | 50.8 mm | 1 " | 2 in | 25.4 mm | 0.6 " | 15.4 mm | 0.068 lb | 31 g | 6 W | 0.5 % | 4-DIP Module | ±1% | 77 % | ITE (Commercial) | Universal Input | 85 VAC 100 V | 264 VAC 370 VDC | 1 |
aimtec | Through Hole | Enclosed | 1.2 A | 5 V | 50.8 mm | 1 " | 2 in | 25.4 mm | 0.6 " | 15.4 mm | 0.068 lb | 31 g | 6 W | 0.5 % | 4-DIP Module | ±1% | 76 % | ITE (Commercial) | Universal Input | 85 VAC 100 V | 264 VAC 370 VDC | 1 |
aimtec | Through Hole | Enclosed | 1.25 A | 3.3 V | 50.8 mm | 1 " | 2 in | 25.4 mm | 0.6 " | 15.4 mm | 0.068 lb | 31 g | 4.1 W | 0.5 % | 4-DIP Module | ±1% | 70 % | ITE (Commercial) | Universal Input | 85 VAC 100 V | 264 VAC 370 VDC | 1 |
aimtec | Through Hole | Enclosed | 660 mA | 9 V | 50.8 mm | 1 " | 2 in | 25.4 mm | 0.6 " | 15.4 mm | 0.068 lb | 31 g | 5.9 W | 0.5 % | 4-DIP Module | ±1% | 74 % | ITE (Commercial) | Universal Input | 85 VAC 100 V | 264 VAC 370 VDC | 1 |
