SN74LVC1G07-Q1 Series

Enhanced product single 1.65-V to 5.5-V buffer with open-drain outputs

Catalog

Enhanced product single 1.65-V to 5.5-V buffer with open-drain outputs

Part	Output Type	Voltage - Supply [Max]	Voltage - Supply [Min]	Logic Type	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Number of Bits per Element	Number of Elements	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	Package / Case	Mounting Type	Supplier Device Package [x]	Supplier Device Package [y]	Current - Output High, Low	Grade	Qualification	Operating Temperature [Max]	Operating Temperature [Min]
Texas Instruments SN74LVC1G07DCKR-S	Open Drain	5.5 V	1.65 V	Buffer Non-Inverting	-	32 mA	1	1	-40 °C	125 °C	SC-70-5	5-TSSOP SC-70-5 SOT-353	Surface Mount
Texas Instruments SN74LVC1G07YEPR	Open Drain	5.5 V	1.65 V	Buffer Non-Inverting	-	32 mA	1	1	-40 °C	85 °C	5-DSBGA	5-XFBGA DSBGA	Surface Mount	1.4	0.9
Texas Instruments SN74LVC1G07QDRYRQ1		5.5 V	1.65 V	Buffer Non-Inverting			1	1	-40 °C	125 °C	6-SON (1.45x1)	6-UFDFN	Surface Mount			32 mA	Automotive	AEC-Q100
Texas Instruments SN74LVC1G07MDCKREP	Open Drain	5.5 V	1.65 V	Buffer Non-Inverting	-	32 mA	1	1			SC-70-5	5-TSSOP SC-70-5 SOT-353	Surface Mount						125 °C	-55 °C
Texas Instruments SN74LVC1G07DCKT	Open Drain	5.5 V	1.65 V	Buffer Non-Inverting	-	32 mA	1	1	-40 °C	125 °C	SC-70-5	5-TSSOP SC-70-5 SOT-353	Surface Mount
Texas Instruments SN74LVC1G07DCKTG4	Open Drain	5.5 V	1.65 V	Buffer Non-Inverting	-	32 mA	1	1	-40 °C	125 °C	SC-70-5	5-TSSOP SC-70-5 SOT-353	Surface Mount
Texas Instruments SN74LVC1G07DRLRG4	Open Drain	5.5 V	1.65 V	Buffer Non-Inverting	-	32 mA	1	1	-40 °C	125 °C	SOT-5	SOT-553	Surface Mount
Texas Instruments SN74LVC1G07QDCKTQ1	Open Drain	5.5 V	1.65 V	Buffer Non-Inverting	-	32 mA	1	1	-40 °C	125 °C	SC-70-5	5-TSSOP SC-70-5 SOT-353	Surface Mount				Automotive	AEC-Q100
Texas Instruments SN74LVC1G07DCKJ	Open Drain	5.5 V	1.65 V	Buffer Non-Inverting	-	32 mA	1	1	-40 °C	125 °C	SC-70-5	5-TSSOP SC-70-5 SOT-353	Surface Mount
Texas Instruments SN74LVC1G07DBVR	Open Drain	5.5 V	1.65 V	Buffer Non-Inverting	-	32 mA	1	1	-40 °C	125 °C	SOT-23-5	SC-74A SOT-753	Surface Mount

Catalog

Enhanced product single 1.65-V to 5.5-V buffer with open-drain outputs

Key Features

• Controlled BaselineOne Assembly/Test Site, One Fabrication SiteExtended Temperature Performance of –55°C to 125°CEnhanced Diminishing Manufacturing Sources (DMS) SupportEnhanced Product-Change NotificationQualification Pedigree(1)Supports 5-V VCCOperationInput and Open-Drain Output AcceptVoltages up to 5.5 VMax tpdof 5.7 ns at 3.3 VLow Power Consumption, 10-µA Max ICC±24-mA Output Drive at 3.3 VIoffSupports Partial-Power-Down Mode OperationLatch-Up Performance Exceeds 100 mA Per JESD 78, Class IIESD Protection Exceeds JESD 222000-V Human-Body Model (A114-A)200-V Machine Model (A115-A)1000-V Charged-Device Model (C101)(1)Component qualification in accordance with JEDEC and industry standards to ensure reliable operation over an extended temperature range. This includes, but is not limited to, Highly Accelerated Stress Test (HAST) or biased 85/85, temperature cycle, autoclave or unbiased HAST, electromigration, bond intermetallic life, and mold compound life. Such qualification testing should not be viewed as justifying use of this component beyond specified performance and environmental limits.Controlled BaselineOne Assembly/Test Site, One Fabrication SiteExtended Temperature Performance of –55°C to 125°CEnhanced Diminishing Manufacturing Sources (DMS) SupportEnhanced Product-Change NotificationQualification Pedigree(1)Supports 5-V VCCOperationInput and Open-Drain Output AcceptVoltages up to 5.5 VMax tpdof 5.7 ns at 3.3 VLow Power Consumption, 10-µA Max ICC±24-mA Output Drive at 3.3 VIoffSupports Partial-Power-Down Mode OperationLatch-Up Performance Exceeds 100 mA Per JESD 78, Class IIESD Protection Exceeds JESD 222000-V Human-Body Model (A114-A)200-V Machine Model (A115-A)1000-V Charged-Device Model (C101)(1)Component qualification in accordance with JEDEC and industry standards to ensure reliable operation over an extended temperature range. This includes, but is not limited to, Highly Accelerated Stress Test (HAST) or biased 85/85, temperature cycle, autoclave or unbiased HAST, electromigration, bond intermetallic life, and mold compound life. Such qualification testing should not be viewed as justifying use of this component beyond specified performance and environmental limits.

Description

The SN74LVC1G07-Q1 is a single channel open-drain buffer/driver qualified for automotive applications. This is designed for 1.65-V to 5.5-V VCCoperation. The output of the SN74LVC1G07-Q1 device is open drain and can be connected to other open-drain outputs to implement active-low wired-OR or active-high wired-AND functions. The maximum sink current is 32 mA. This device is fully specified for partial-power-down applications using Ioff.The Ioffcircuitry disables the outputs, preventing damaging current backflow through the device when it is powered down. The SN74LVC1G07-Q1 is a single channel open-drain buffer/driver qualified for automotive applications. This is designed for 1.65-V to 5.5-V VCCoperation. The output of the SN74LVC1G07-Q1 device is open drain and can be connected to other open-drain outputs to implement active-low wired-OR or active-high wired-AND functions. The maximum sink current is 32 mA. This device is fully specified for partial-power-down applications using Ioff.The Ioffcircuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.
