VNB14 Series

Catalog

IC PWR DRIVER N-CHAN 1:1 D2PAK

Part	Operating Temperature [Min]	Operating Temperature [Max]	Input Type	Rds On (Typ)	Switch Type	Current - Output (Max) [Max]	Number of Outputs	Package / Case	Fault Protection	Voltage - Supply (Vcc/Vdd)	Output Configuration	Voltage - Load [Max]	Ratio - Input:Output	Supplier Device Package	Mounting Type	Interface	Output Type
STMicroelectronics VNB14NV04	-40 °C	150 °C	Non-Inverting	35 mOhm	General Purpose	12 A	1	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	Current Limiting (Fixed) Over Temperature Over Voltage	Not Required	Low Side	36 V	1:1	D2PAK	Surface Mount	On/Off	N-Channel
STMicroelectronics VNB14NV04-E	-40 °C	150 °C	Non-Inverting	35 mOhm	General Purpose	12 A	1	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	Current Limiting (Fixed) Over Temperature Over Voltage	Not Required	Low Side	36 V	1:1	D2PAK	Surface Mount	On/Off	N-Channel
