UUR Series

Manufacturer: Nichicon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - SMD 10VOLTS 220UF 20% AEC-Q200

Part	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Mounting Type	Capacitance	Size / Dimension [diameter]	Size / Dimension [diameter]	Ripple Current @ Low Frequency	Voltage - Rated	Ripple Current @ High Frequency	Package / Case	Lifetime @ Temp.	Operating Temperature [Max]	Operating Temperature [Min]	Surface Mount Land Size [y]	Surface Mount Land Size [x]	Surface Mount Land Size [y]	Surface Mount Land Size [x]	Tolerance	Applications	Height - Seated (Max) [Max]
Nichicon UUR1A221MCL6GS	8 mm	0.315 in	Surface Mount	220 µF	0.248 "	6.3 mm	173 mA	10 V	224.9 mA	Radial Can - SMD	2000 Hrs	85 °C	-40 C	0.26 in	6.6 mm	6.6 mm	0.26 in	20 %	General Purpose
Nichicon UUR2A4R7MCL1GS	0.256 in		Surface Mount	4.7 µF	0.315 in	8 mm	40 mA	100 V		Radial Can - SMD	2000 Hrs	85 °C	-40 C	0.327 in	8.3 mm	8.3 mm	0.327 in	20 %	General Purpose	6.5 mm
Nichicon UUR1C471MNL1GS	10.5 mm	0.413 "	Surface Mount	470 µF	0.394 in	10 mm	330 mA	16 V	429 mA	Radial Can - SMD	2000 Hrs	85 °C	-40 C	0.406 in	10.3 mm	10.3 mm	0.406 "	20 %	General Purpose
Nichicon UUR1J100MCL1GS	0.256 in		Surface Mount	10 µF	0.315 in	8 mm	46 mA	63 V	76.82 mA	Radial Can - SMD	2000 Hrs	85 °C	-40 C	0.327 in	8.3 mm	8.3 mm	0.327 in	20 %	General Purpose	6.5 mm
