TSM9434 Series

Catalog

-20V, -6.4A, SINGLE P-CHANNEL PO

Part	Vgs (Max) [Max]	Package / Case	Package / Case	Package / Case	Mounting Type	Gate Charge (Qg) (Max) @ Vgs [Max]	Power Dissipation (Max)	Drain to Source Voltage (Vdss)	FET Type	Input Capacitance (Ciss) (Max) @ Vds [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Current - Continuous Drain (Id) @ 25°C	Technology	Drive Voltage (Max Rds On, Min Rds On) [Max]	Drive Voltage (Max Rds On, Min Rds On) [Min]	Supplier Device Package	Vgs(th) (Max) @ Id	Rds On (Max) @ Id, Vgs
Taiwan Semiconductor Corporation TSM9434CS	8 V	0.154 in	8-SOIC	3.9 mm	Surface Mount	19 nC	2.5 W	20 V	P-Channel	1020 pF	150 °C	-55 °C	6.4 A	MOSFET (Metal Oxide)	2.5 V	4.5 V	8-SOP	1 V	40 mOhm
Taiwan Semiconductor Corporation TSM9434CS RLG	8 V	0.154 in	8-SOIC	3.9 mm	Surface Mount	19 nC	2.5 W	20 V	P-Channel	1020 pF	150 °C	-55 °C	6.4 A	MOSFET (Metal Oxide)	2.5 V	4.5 V	8-SOP	1 V	40 mOhm
