12038GE Series
Manufacturer: NMB TECHNOLOGIES
Beta
⌘K
DC AXIAL FAN, 12 V, CIRCULAR, 120 MM, 38 MM, BALL BEARING, 45.2 CFM
| Part | Material - Blade | Air Flow | Air Flow | Lifetime @ Temp. | Voltage Range [Min] | Voltage Range [Max] | Material - Frame | Current Rating (Amps) | Termination | Width [y] | Bearing Type | Features | Power (Watts) | Size / Dimension | Size / Dimension [diameter] | Voltage - Rated | RPM | Noise | Operating Temperature [Max] | Operating Temperature [Min] | Static Pressure | Static Pressure | Fan Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NMB TECHNOLOGIES | Plastic | 45 CFM | 1.26 m³/min | 70000 Hrs | 7 V | 13.2 VDC | Plastic | 0.24 A | 2 Wire Leads | 38 mm | Ball | Auto Restart | 2.88 W | Round | 120 mm | 12 VDC | 1950 RPM | 38 dB(A) | 40 °C | -40 C | 0.31 in H2O | 77.2 Pa | Tubeaxial |
