ER8-20S Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN RCPT 20POS SMD GOLD
| Part | Mated Stacking Heights | Pitch | Pitch | Mounting Type | Features | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Height Above Board [z] | Height Above Board [z] | Number of Positions | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | 9 mm 12 mm | 0.8 mm | 0.031 in | Surface Mount | Board Guide | Gold | 30 Áin | 0.76 Ám | 2 | 7.24 mm | 0.285 in | 20 | Receptacle Outer Shroud Contacts |
 Hirose Electric Co Ltd | 7 mm 10 mm | 0.8 mm | 0.031 in | Surface Mount | Board Guide | Gold | 30 Áin | 0.76 Ám | 2 | 5.35 mm | 0.211 in | 20 | Receptacle Outer Shroud Contacts |
