HIF3BD Series

Catalog

CONN HEADER VERT 10POS 2.54MM

Part	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Mounting Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Material Flammability Rating	Current Rating (Amps)	Contact Shape	Insulation Height [z]	Insulation Height [z]	Contact Type	Style	Shrouding	Number of Positions Loaded	Connector Type	Number of Rows [custom]	Features	Contact Length - Post	Contact Length - Post	Insulation Material	Contact Finish - Post	Contact Finish - Mating	Insulation Color	Contact Material	Termination	Pitch - Mating	Pitch - Mating	Number of Positions	Voltage Rating	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Row Spacing	Row Spacing	Wire Type	Contact Finish Thickness	Contact Finish Thickness	Color	Cable Termination	Wire Gauge	Pitch	Pitch	Contact Finish	Contact Length - Mating	Contact Length - Mating	Overall Contact Length	Overall Contact Length	Insulation Height	Insulation Height	Overall Contact Length [x]	Overall Contact Length [x]
Hirose Electric Co Ltd HIF3BD-10PA-2.54DSA(63)	78.7 µin	2 µm	Through Hole	8 µin	0.203 µm	UL94 V-0	Varies by Wire Gauge	Square	0.701 in	17.8 mm	Male Pin	Board to Cable/Wire	Shrouded - 4 Wall	All	Header	2	Keying Slot	0.13 "	3.3 mm	Polybutylene Terephthalate (PBT)	Tin	Gold	Black	Brass	Solder	0.1 "	2.54 mm	10	200 V	Latch Lock/Eject Hooks	-55 C	85 °C	0.1 in	2.54 mm
Hirose Electric Co Ltd HIF3BD-10PD-2.54R-MC(63)			Free Hanging (In-Line)								Male Pin				Plug	2	Feed Through Polarizing Key Strain Relief											10		Latch Lock/Eject Hooks					2.54 mm	0.1 "	Ribbon Cable	0.2 µm	7.87 Áin	Black	IDC	28 AWG	0.1 "	2.54 mm	Gold
Hirose Electric Co Ltd HIF3BD-10PA-2.54DSA(75)	78.7 µin	2 µm	Through Hole	30 Áin	0.76 Ám	UL94 V-0		Square	0.701 in	17.8 mm	Male Pin	Board to Cable/Wire	Shrouded - 4 Wall	All	Header	2		0.13 "	3.3 mm	Polybutylene Terephthalate (PBT)	Tin	Gold	Black	Brass	Solder	0.1 "	2.54 mm	10	200 V	Latch Lock/Eject Hooks	-55 C	85 °C	0.1 in	2.54 mm												6 mm	0.236 in	16.7 mm	0.657 in
Hirose Electric Co Ltd HIF3BD-10P-2.54W(63)			Through Hole			UL94 V-0	Varies by Wire Gauge	Square	0.701 in	17.8 mm	Male Pin	Board to Cable/Wire	Shrouded - 4 Wall	All	Header	2	Keying Slot			Polybutylene Terephthalate (PBT)			Black	Brass	Wire Wrap	0.1 "	2.54 mm	10	200 V	Latch Lock/Eject Hooks	-55 C	85 °C	0.1 in	2.54 mm
Hirose Electric Co Ltd HIF3BD-10PA-2.54DS(72)			Right Angle Through Hole	12 Áin	0.3 Ám	UL94 V-0		Square			Male Pin	Board to Cable/Wire	Shrouded - 4 Wall	All	Header	2	Mounting Flange	0.118 in	3 mm	Polybutylene Terephthalate (PBT)		Gold	Black	Brass	Solder	0.1 "	2.54 mm	10	200 V	Latch Lock/Eject Hooks	-55 C	85 °C	0.1 in	2.54 mm												6 mm	0.236 in			0.335 "	8.51 mm
Hirose Electric Co Ltd HIF3BD-10P-2.54W			Through Hole	8 µin	0.203 µm	UL94 V-0		Square	0.701 in	17.8 mm	Male Pin	Board to Cable/Wire	Shrouded - 4 Wall	All	Header	2		0.516 in	13.1 mm	Polybutylene Terephthalate (PBT)		Gold	Black	Brass	Wire Wrap	0.1 "	2.54 mm	10	200 V	Latch Lock/Eject Hooks	-55 C	85 °C	0.1 in	2.54 mm												6 mm	0.236 in					1.043 in	26.5 mm
Hirose Electric Co Ltd HIF3BD-10PA-2.54DSA(71)	78.7 µin	2 µm	Through Hole	8 µin	0.203 µm	UL94 V-0		Square	0.701 in	17.8 mm	Male Pin	Board to Cable/Wire	Shrouded - 4 Wall	All	Header	2		0.13 "	3.3 mm	Polybutylene Terephthalate (PBT)	Tin	Gold	Black	Brass	Solder	0.1 "	2.54 mm	10	200 V	Latch Lock/Eject Hooks	-55 C	85 °C	0.1 in	2.54 mm												6 mm	0.236 in	16.7 mm	0.657 in
Hirose Electric Co Ltd HIF3BD-10PA-2.54WB(63)	78.7 µin	2 µm	Right Angle Through Hole	8 µin	0.203 µm	UL94 V-0	Varies by Wire Gauge	Square			Male Pin	Board to Cable/Wire	Shrouded - 4 Wall	All	Header	2		0.118 in	3 mm	Polybutylene Terephthalate (PBT)	Tin	Gold	Black	Brass	Solder	0.1 "	2.54 mm	10	200 V	Latch Lock/Eject Hooks	-55 C	85 °C	0.1 in	2.54 mm																0.335 "	8.51 mm
Hirose Electric Co Ltd HIF3BD-10PA-2.54DS(71)	78.7 µin	2 µm	Right Angle Through Hole	8 µin	0.203 µm	UL94 V-0		Square			Male Pin	Board to Cable/Wire	Shrouded - 4 Wall	All	Header	2	Mounting Flange	0.118 in	3 mm	Polybutylene Terephthalate (PBT)	Tin	Gold	Black	Brass	Solder	0.1 "	2.54 mm	10	200 V	Latch Lock/Eject Hooks	-55 C	85 °C	0.1 in	2.54 mm												6 mm	0.236 in			0.335 "	8.51 mm
Hirose Electric Co Ltd HIF3BD-10PA-2.54DS(63)	78.7 µin	2 µm	Right Angle Through Hole	8 µin	0.203 µm	UL94 V-0	Varies by Wire Gauge	Square			Male Pin	Board to Cable/Wire	Shrouded - 4 Wall	All	Header	2		0.118 in	3 mm	Polybutylene Terephthalate (PBT)	Tin	Gold	Black	Brass	Solder	0.1 "	2.54 mm	10	200 V	Latch Lock/Eject Hooks	-55 C	85 °C	0.1 in	2.54 mm																0.335 "	8.51 mm
