09533GA Series
Manufacturer: NMB TECHNOLOGIES
Beta
⌘K
BLOWERS & CENTRIFUGAL FANS DC BLOWER, 95X33MM, 24VDC, 20.5CFM, 3-LEAD WIRES, TACHOMETER
| Part | Lifetime @ Temp. | Material - Blade | Voltage Range [Min] | Voltage Range [Max] | Material - Frame | Air Flow | Air Flow | Current Rating (Amps) | RPM | Voltage - Rated | Termination | Bearing Type | Size / Dimension [x] | Size / Dimension | Size / Dimension [z] | Fan Type | Width | Power (Watts) | Features | Operating Temperature [Min] | Operating Temperature [Max] | Noise | Static Pressure | Static Pressure |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NMB TECHNOLOGIES | 100000 Hrs | Plastic | 10 VDC | 27.6 VDC | Plastic | 0.571 m³/min | 20.4 CFM | 0.21 A | 2700 RPM | 24 VDC | 3 Wire Leads | Ball | 97 mm | Square/Rounded | 93.5 mm | Blower | 33 mm | 5.04 W | Auto Restart Speed Sensor (Tach) | -10 °C | 60 °C | 47.5 dB | ||
NMB TECHNOLOGIES | 100000 Hrs | Plastic | 10 VDC | 27.6 VDC | Plastic | 0.692 m³/min | 24.7 CFM | 0.33 A | 3200 RPM | 24 VDC | 3 Wire Leads | Ball | 97 mm | Square/Rounded | 93.5 mm | Blower | 33 mm | 7.92 W | Auto Restart Locked Rotor Sensor | -10 °C | 60 °C | 51.5 dB | 0.9 in H2O | 224.2 Pa |
 NMB TECHNOLOGIES | 0.571 m³/min | 20.4 CFM | 2700 RPM | 12 VDC | 3 Wire Leads | Ball | 97 mm | Square/Rounded | 93.5 mm | Blower | 33 mm | 4.8 W | Auto Restart Locked Rotor Sensor | 47.5 dB | ||||||||||
NMB TECHNOLOGIES | 0.571 m³/min | 20.4 CFM | 2700 RPM | 12 VDC | 2 Wire Leads | Ball | 97 mm | Square/Rounded | 93.5 mm | Blower | 33 mm | 4.8 W | Auto Restart | -10 °C | 60 °C | 47.5 dB |
