LF13WBRB Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN RCPT MALE
| Part | Contact Finish - Mating | Termination | Applications | Number of Positions | Mounting Feature | Shielding | Connector Type | Operating Temperature [Max] | Operating Temperature [Min] | Insert Material | Primary Material | Current Rating (Amps) | Ingress Protection | Orientation | Contact Material | Shell Material | Material Flammability Rating | Voltage Rating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Color | Shell Finish | Shell Size - Insert [custom] | Fastening Type | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Gold | Solder | Industrial Telecommunications | 11 | Bulkhead - Front Side Nut | Shielded | Receptacle Male Pins | 85 °C | -25 °C | Polyphenylene Sulfide (PPS) | Metal | 2 A | IP67/IP68 | Keyed | Copper Alloy | Zinc Alloy | UL94 V-0 | 30 VAC 42 VDC | 7.87 Áin | 0.2 Ám | Silver | Nickel | 13 | Bayonet Lock | Panel Mount Through Hole |
 Hirose Electric Co Ltd | Gold | Solder | Industrial Telecommunications | 20 | Bulkhead - Front Side Nut | Shielded | Receptacle Male Pins | 85 °C | -25 °C | Polyphenylene Sulfide (PPS) | Metal | 2 A | IP67/IP68 | Keyed | Copper Alloy | Zinc Alloy | UL94 V-0 | 30 VAC 42 VDC | 7.87 Áin | 0.2 Ám | Silver | Nickel | 13 | Bayonet Lock | Panel Mount Through Hole |
 Hirose Electric Co Ltd | Gold | Solder | Industrial Telecommunications | 20 | Bulkhead - Front Side Nut | Shielded | Receptacle Female Sockets | 85 °C | -25 °C | Polyphenylene Sulfide (PPS) | Metal | 2 A | IP67/IP68 | Keyed | Copper Alloy | Zinc Alloy | UL94 V-0 | 30 VAC 42 VDC | Silver | Nickel | 13 | Bayonet Lock | Panel Mount Through Hole | ||
 Hirose Electric Co Ltd | Gold | Industrial Telecommunications | 20 | Bulkhead - Front Side Nut | Receptacle Female Sockets | 85 °C | -25 °C | Polyphenylene Sulfide (PPS) | Metal | 2 A | IP67/IP68 | Keyed | Copper Alloy | Zinc Alloy | UL94 V-0 | 30 VAC 42 VDC | 8 µin | 0.203 µm | Silver | Nickel | 13 | Bayonet Lock | Panel Mount |
