BSC025 Series

Manufacturer: INFINEON

Catalog

OPTIMOS™ 3 N-CHANNEL POWER MOSFET 30 V ; SUPERSO8 5X6 PACKAGE; 2.5 MOHM;

Part	Rds On (Max) @ Id, Vgs	Vgs (Max)	FET Type	Supplier Device Package	Package / Case	Mounting Type	Vgs(th) (Max) @ Id	Technology	Drive Voltage (Max Rds On, Min Rds On)	Gate Charge (Qg) (Max) @ Vgs	Current - Continuous Drain (Id) @ 25°C	Operating Temperature [Max]	Operating Temperature [Min]	Input Capacitance (Ciss) (Max) @ Vds [Max]	Power Dissipation (Max)	Drain to Source Voltage (Vdss)	Gate Charge (Qg) (Max) @ Vgs [Max]	Input Capacitance (Ciss) (Max) @ Vds
INFINEON BSC025N03LSGATMA1	2.5 mOhm	20 V	N-Channel	PG-TDSON-8-5	8-PowerTDFN	Surface Mount	2.2 V	MOSFET (Metal Oxide)	4.5 V 10 V	74 nC	25 A 100 A	150 °C	-55 °C	6100 pF	2.5 W 83 W	30 V
INFINEON BSC025N03MSGATMA1	2.5 mOhm	20 V	N-Channel	PG-TDSON-8-1	8-PowerTDFN	Surface Mount	2 V	MOSFET (Metal Oxide)	4.5 V 10 V		23 A 100 A	150 °C	-55 °C	7600 pF	2.5 W 83 W	30 V	98 nC
INFINEON BSC025N08LS5ATMA1	2.5 mOhm	20 V	N-Channel	PG-TDSON-8-7	8-PowerTDFN	Surface Mount	2.3 V	MOSFET (Metal Oxide)	4.5 V 10 V		100 A	150 °C	-55 °C		2.5 W 156 W	80 V	55 nC	7500 pF
