ODD-8 Series

Catalog

SENSOR PHOTODIODE 940NM LOCAP

Part	Mounting Type	Wavelength	Active Area	Voltage - DC Reverse (Vr) (Max) [Max]	Responsivity @ nm	Response Time	Operating Temperature [Max]	Operating Temperature [Min]	Spectral Range [Max]	Spectral Range [Min]
Opto Diode Corp ODD-8SMD	Surface Mount	940 nm	8 mm˛	170 V	0.44 A/W	50 ns	85 °C	-25 °C	1100 nm	400 nm
Opto Diode Corp ODD-8SMD-DF	Surface Mount	940 nm	8 mm˛	170 V	0.44 A/W	50 ns	85 °C	-25 °C	1100 nm	730 nm
