ACST4 Series

Catalog

TRIAC SENS GATE 800V 4A TO220FP

Part	Current - Non Rep. Surge 50, 60Hz (Itsm)	Mounting Type	Supplier Device Package	Package / Case	Configuration	Voltage - Off State	Current - Hold (Ih) (Max) [Max]	Voltage - Gate Trigger (Vgt) (Max)	Current - On State (It (RMS)) (Max) [Max]	Triac Type	Current - Gate Trigger (Igt) (Max) [Max]	Voltage - Gate Trigger (Vgt) (Max) [Max] [custom]	Operating Temperature [Max]	Operating Temperature [Min]
STMicroelectronics ACST4-8SFP	30 A 33 A	Through Hole	TO-220FP	TO-220-3 Full Pack	Single	800 V	20 mA	1 V	4 A	Logic - Sensitive Gate	10 mA
STMicroelectronics ACST4-7SB	30 A 33 A	Surface Mount	DPAK	DPAK (2 Leads + Tab) SC-63 TO-252-3	Single	700 V	35 mA		4 A	Standard	25 mA	1.1 V	125 °C	-30 °C
STMicroelectronics ACST4-8SB-TR	30 A 33 A	Surface Mount	DPAK	DPAK (2 Leads + Tab) SC-63 TO-252-3	Single	800 V	20 mA	1 V	4 A	Logic - Sensitive Gate	10 mA
STMicroelectronics ACST435-8B	30 A 32 A	Surface Mount	DPAK	DPAK (2 Leads + Tab) SC-63 TO-252-3	Single	800 V	25 mA		4 A	Standard	35 mA	1.1 V	125 °C	-40 C
STMicroelectronics ACST410-8FP	30 A 32 A	Through Hole	TO-220FPAB	TO-220-3 Full Pack	Single	800 V	20 mA	1 V	4 A	Logic - Sensitive Gate	10 mA		125 °C	-40 C
STMicroelectronics ACST435-8BTR	30 A 32 A	Surface Mount	DPAK	DPAK (2 Leads + Tab) SC-63 TO-252-3	Single	800 V	25 mA		4 A	Standard	35 mA	1.1 V	125 °C	-40 C
STMicroelectronics ACST4-7CB-TR	30 A 33 A	Surface Mount	DPAK	DPAK (2 Leads + Tab) SC-63 TO-252-3	Single	700 V	35 mA		4 A	Standard	25 mA	1.1 V	125 °C	-30 °C
STMicroelectronics ACST410-8BTR	30 A 32 A	Surface Mount	DPAK	DPAK (2 Leads + Tab) SC-63 TO-252-3	Single	800 V	20 mA	1 V	4 A	Logic - Sensitive Gate	10 mA		125 °C	-40 C
