SIB911 Series

Catalog

MOSFET 2P-CH 20V 2.6A SC75-6L

Part	Rds On (Max) @ Id, Vgs	Input Capacitance (Ciss) (Max) @ Vds	Gate Charge (Qg) (Max) @ Vgs [Max]	Drain to Source Voltage (Vdss)	Operating Temperature [Min]	Operating Temperature [Max]	Current - Continuous Drain (Id) @ 25°C	Package / Case	Mounting Type	Vgs(th) (Max) @ Id	Supplier Device Package	Power - Max [Max]	Configuration	Technology
Vishay General Semiconductor - Diodes Division SIB911DK-T1-GE3	295 mOhm	115 pF	4 nC	20 V	-55 °C	150 °C	2.6 A	PowerPAK® SC-75-6L Dual	Surface Mount	1 V	PowerPAK® SC-75-6L Dual	3.1 W	2 P-Channel	MOSFET (Metal Oxide)
