FERD20H100S Series

100 V, 20 A Field-Effect Rectifier Diode (FERD)

Catalog

100 V, 20 A Field-Effect Rectifier Diode (FERD)

Part	Operating Temperature - Junction [Max]	Voltage - Forward (Vf) (Max) @ If	Current - Reverse Leakage @ Vr	Speed	Technology	Voltage - DC Reverse (Vr) (Max) [Max]	Mounting Type	Supplier Device Package	Package / Case
STMicroelectronics FERD20H100SFP	175 ░C	705 mV	140 µA	200 mA 500 ns	FERD (Field Effect Rectifier Diode)	100 V	Through Hole	TO-220FPAB	TO-220-3 Full Pack

Catalog

100 V, 20 A Field-Effect Rectifier Diode (FERD)

Description

The device is based on a proprietary technology that achieves the best in class VF/IRtrade-off for a given silicon surface. This 100 V rectifier has been optimized for use in confined casing applications where both efficiency and thermal performance matter. With a lower dependency of leakage current (IR) and forward voltage (VF) in function of temperature, the thermal runaway risk is reduced. Therefore, it can advantageously replace 100 V Schottky diodes.
