846-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Number of Positions/Bay/Row | Card Type | Number of Rows [custom] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Termination | Contact Material | Read Out | Pitch | Pitch | Contact Type | Color | Number of Positions | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 24 | Non Specified - Dual Edge | 2 | Right Angle Through Hole | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Dual | 3.18 mm | 0.125 in | Cantilever | Green | 48 | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 24 | Non Specified - Dual Edge | 2 | Through Hole | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Dual | 3.18 mm | 0.125 in | Cantilever | Green | 48 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 24 | Non Specified - Dual Edge | 2 | Through Hole | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Dual | 3.18 mm | 0.125 in | Cantilever | Green | 48 | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 " | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 48 | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Single | 3.18 mm | 0.125 in | Cantilever | Green | 48 | Side Mount Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | 1 | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 24 | Non Specified - Dual Edge | 2 | Through Hole | 0.25 Ám | 10 Áin | Wire Wrap | Copper Alloy | Dual | 3.18 mm | 0.125 in | Cantilever | Green | 48 | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 24 | Non Specified - Dual Edge | 2 | Through Hole | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Copper Alloy | Dual | 3.18 mm | 0.125 in | Cantilever | Green | 48 | Floating Bobbin Flush Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2.95 mm | 0.116 " | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 24 | Non Specified - Dual Edge | 2 | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Copper Alloy | Dual | 3.18 mm | 0.125 in | Cantilever | Green | 48 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | Card Extender | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 24 | Non Specified - Dual Edge | 2 | Through Hole | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Dual | 3.18 mm | 0.125 in | Cantilever | Green | 48 | Flush Mount Side Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 24 | Non Specified - Dual Edge | 2 | Through Hole | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Dual | 3.18 mm | 0.125 in | Cantilever | Green | 48 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 " | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Gold | 48 | Non Specified - Single Edge | Right Angle Through Hole | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Single | 3.18 mm | 0.125 in | Cantilever | Green | 48 | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | 1 | 1 |
