US2882 Series

Catalog

MAGNETIC SWITCH LATCH TSOT23-3

Part	Current - Output (Max) [Max]	Mounting Type	Current - Supply (Max) [Max]	Polarization	Voltage - Supply [Min]	Voltage - Supply [Max]	Test Condition	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Function	Output Type	Technology	Supplier Device Package	Sensing Range [custom]	Sensing Range [custom]	Test Condition
Melexis Technologies NV US2882ESE-AAA-000-RE	50 mA	Surface Mount	5 mA	South Pole	3.5 V	24 V	85°C	SC-59 SOT-23-3 TO-236-3	85 C	-40 ¯C	Latch	Open Drain	Hall Effect	TSOT-23-3	6 mT	-6 mT
Melexis Technologies NV US2882EUA-AAA-000-BU	50 mA	Through Hole	5 mA	South Pole	3.5 V	24 V	85°C	TO-226-3 TO-92-3 Short Body	85 C	-40 ¯C	Latch	Open Drain	Hall Effect	TO-92-3	6 mT	-6 mT
Melexis Technologies NV US2882LSE-AAA-000-RE	50 mA	Surface Mount	5 mA	South Pole	3.5 V	24 V		SC-59 SOT-23-3 TO-236-3	150 °C	-40 °C	Latch	Open Drain	Hall Effect	TSOT-23-3	6 mT	-6 mT	150 °C
Melexis Technologies NV US2882LUA-AAA-000-SP	50 mA	Through Hole	5 mA	South Pole	3.5 V	24 V		TO-226-3 TO-92-3 Short Body	150 °C	-40 °C	Latch	Open Drain	Hall Effect	TO-92-3	6 mT	-6 mT	150 °C
Melexis Technologies NV US2882LUA-AAA-000-BU	50 mA	Through Hole	5 mA	South Pole	3.5 V	24 V		TO-226-3 TO-92-3 Short Body	150 °C	-40 °C	Latch	Open Drain	Hall Effect	TO-92-3	6 mT	-6 mT	150 °C
Melexis Technologies NV US2882EUA-AAA-000-SP	50 mA	Through Hole	5 mA	South Pole	3.5 V	24 V	85°C	TO-226-3 TO-92-3 Short Body	85 C	-40 ¯C	Latch	Open Drain	Hall Effect	TO-92-3	6 mT	-6 mT
Melexis Technologies NV US2882ESE-AAA-000-SP	50 mA	Surface Mount	5 mA	South Pole	3.5 V	24 V	85°C	SC-59 SOT-23-3 TO-236-3	85 C	-40 ¯C	Latch	Open Drain	Hall Effect	TSOT-23-3	6 mT	-6 mT
Melexis Technologies NV US2882LSE-AAA-000-SP	50 mA	Surface Mount	5 mA	South Pole	3.5 V	24 V		SC-59 SOT-23-3 TO-236-3	150 °C	-40 °C	Latch	Open Drain	Hall Effect	TSOT-23-3	6 mT	-6 mT	150 °C
