807-037 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FML 37POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Rows | Contact Type | Contact Material | Number of Positions | Color | Termination | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Contact Finish | Number of Positions/Bay/Row | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Semi Bellows | Copper Alloy | 37 | Green | Solder | Single | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Tin | 37 | Female | 125 °C | -40 C | Non Specified - Single Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Semi Bellows | Copper Alloy | 37 | Green | Solder | Single | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Tin | 37 | Female | 125 °C | -40 C | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Semi Bellows | Copper Alloy | 74 | Green | Solder | Dual | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Tin | 37 | Female | 125 °C | -40 C | Non Specified - Dual Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Semi Bellows | Copper Alloy | 37 | Green | Solder | Single | 3.96 mm | 0.156 in | Tin | 37 | Female | 125 °C | -40 C | Non Specified - Single Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Semi Bellows | Copper Alloy | 74 | Green | Solder | Dual | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Gold | 37 | Female | 125 °C | -40 C | Non Specified - Dual Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Semi Bellows | Copper Alloy | 74 | Green | Solder | Dual | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Gold | 37 | Female | 125 °C | -40 C | Non Specified - Dual Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Semi Bellows | Copper Alloy | 37 | Green | Solder | Single | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Tin | 37 | Female | 125 °C | -40 C | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Semi Bellows | Copper Alloy | 74 | Green | Solder Eyelet(s) | Dual | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 3.96 mm | 0.156 in | Gold | 37 | Female | 125 °C | -40 C | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Semi Bellows | Copper Alloy | 74 | Green | Solder Eyelet(s) | Dual | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Gold | 37 | Female | 125 °C | -40 C | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Semi Bellows | Copper Alloy | 74 | Green | Solder | Dual | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Gold | 37 | Female | 125 °C | -40 C | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 0.25 Ám | 10 Áin |
