VN5E050 Series
Manufacturer: STMicroelectronics
Beta
⌘K
IC PWR SWTCH N-CHAN 1:1 PWRSSO12
| Part | Number of Outputs | Operating Temperature [Min] | Operating Temperature [Max] | Interface | Switch Type | Voltage - Supply (Vcc/Vdd) | Output Configuration | Output Type | Current - Output (Max) [Max] | Package / Case | Mounting Type | Fault Protection | Voltage - Load [Min] | Voltage - Load [Max] | Rds On (Typ) | Input Type | Ratio - Input:Output | Features | Supplier Device Package | Package / Case | Package / Case | Supplied Contents | Contents | Primary Attributes | Function | Type | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 STMicroelectronics | 1 | -40 °C | 150 °C | On/Off | General Purpose | Not Required | High Side | N-Channel | 19 A | PowerSSO-12 | Surface Mount | Current Limiting (Fixed) Over Temperature Over Voltage | 4.5 V | 28 V | 50 mOhm | Non-Inverting | 1:1 | Auto Restart | PowerSSO-12™ | ||||||||
STMicroelectronics | 1 | -40 °C | 150 °C | On/Off | General Purpose | Not Required | High Side | N-Channel | 19 A | PowerSSO-12 | Surface Mount | Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage | 4.5 V | 28 V | 50 mOhm | Non-Inverting | 1:1 | Auto Restart | PowerSSO-12™ | ||||||||
 STMicroelectronics | 1 | -40 °C | 150 °C | On/Off | General Purpose | Not Required | High Side | N-Channel | 19 A | 16-SOIC | Surface Mount | Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage | 4.5 V | 28 V | 50 mOhm | Non-Inverting | 1:1 | Auto Restart | 16-SO | 7.5 mm | 0.295 " | ||||||
 STMicroelectronics | Board(s) | Board(s) | 1-Channel (Single) | High Side Driver (Internal FET) | Power Management | VN5E050AJ |
