UFW Series

Manufacturer: Nichicon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED 10UF 100V 20%

Part	Capacitance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Tolerance	Ripple Current @ High Frequency	Applications	Voltage - Rated	Lifetime @ Temp.	Mounting Type	Polarization	Lead Spacing	Lead Spacing	Size / Dimension [diameter]	Size / Dimension [diameter]	Package / Case	Ripple Current @ Low Frequency	Operating Temperature [Max]	Operating Temperature [Min]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Lead Spacing
Nichicon UFW2A100MED1TD	10 µF	0.492 in	12.5 mm	20 %	150 mA	Audio	100 V	2000 Hrs	Through Hole	Polar	2.5 mm	0.098 in	0.248 "	6.3 mm	Can Radial	75 mA	85 °C	-40 C
Nichicon UFW1J331MPD1TD	330 µF			20 %	975 mA	Audio	63 V	2000 Hrs	Through Hole	Polar	5 mm	0.197 "	0.394 in	10 mm	Can Radial	650 mA	85 °C	-40 C	0.866 in	22 mm
Nichicon UFW1A331MED	330 µF			20 %	405 mA	Audio	10 V	2000 Hrs	Through Hole	Polar	2.5 mm	0.098 in	0.248 "	6.3 mm	Can Radial	270 mA	85 °C	-40 C			11 mm	0.433 in
Nichicon UFW1E470MDD1TD	47 µF	0.492 in	12.5 mm	20 %	230 mA	Audio	25 VDC	2000 Hrs	Through Hole	Polar	2.5 mm	0.098 in	0.197 in	5 mm	Can Radial	115 mA	85 °C	-40 C
Nichicon UFW0J332MPD1TD	3.3 mF			20 %	1.3455 A	Audio	6.3 VDC	2000 Hrs	Through Hole	Polar	5 mm	0.197 "	0.394 in	10 mm	Can Radial	1.17 A	85 °C	-40 C	0.866 in	22 mm
Nichicon UFW1E331MPD1TD	330 µF	14 mm		20 %		Audio	25 VDC	2000 Hrs	Through Hole	Polar	5 mm	0.197 "	0.394 in	10 mm	Can Radial	420 mA	85 °C	-40 C					0.551 in
Nichicon UFW2A332MRD	3.3 mF	50 mm		20 %	3.335 A	Audio	100 V	2000 Hrs	Through Hole	Polar	0.492 in		0.984 "	25 mm	Can Radial	2.9 A	85 °C	-40 C					1.969 in	12.5 mm
Nichicon UFW1J332MRD	3.3 mF	40 mm		20 %	3.105 A	Audio	63 V	2000 Hrs	Through Hole	Polar	10 mm	0.394 in	0.787 "	20 mm	Can Radial	2.7 A	85 °C	-40 C					1.575 in
Nichicon UFW1H682MRD	6800 µF	50 mm		20 %	4.025 A	Audio	50 VDC	2000 Hrs	Through Hole	Polar	10 mm	0.394 in	0.866 "	22 mm	Can Radial	3.5 A	85 °C	-40 C					1.969 in
Nichicon UFW1C332MHD1TO	3.3 mF	27 mm		20 %	1.955 A	Audio	16 V	2000 Hrs	Through Hole	Polar	5 mm	0.197 "	0.492 in	12.5 mm	Can Radial	1.7 A	85 °C	-40 C					1.063 in
