28T Series

Ferrite Cable Cores FT,NIZN,PC

Manufacturer: Laird Technologies EMI

Catalog

Ferrite Cable Cores FT,NIZN,PC

Catalog

Ferrite Cable Cores FT,NIZN,PC

Part	Gap	Tolerance	Effective Length (le) mm	Effective Area (Ae) mm²	Diameter [diameter]	Diameter [diameter]	Finish	Height [z]	Height	Inductance Factor (Al)	Material	Core Type	Initial Permeability (µi)	Effective Length (le) mm [x]	Height	Core Factor (ΣI/A) mm⁻¹	Height [z]	Effective Length (le) mm [custom]	Effective Area (Ae) mm² [custom]	Effective Magnetic Volume (Ve) mmł	Core Factor (ΣI/A) mm⁻ą	Effective Area (Ae) mm˛	Effective Magnetic Volume (Ve) mm³	Effective Area (Ae) mm² [custom]
Laird Technologies EMI 28T0130-00P	Ungapped	20 %	6.2 mm	1.2 mm²	0.13 in	3.3 mm	Parylene	0.051 in	1.29 mm	206 nH	28	Toroid	850
Laird Technologies EMI 28T0135-00P	Ungapped	20 %		1.06 mm²	0.136 in	3.45 mm	Parylene	0.051 in	1.29 mm	142 nH	28	Toroid	850	7.57 mm
Laird Technologies EMI 28T0155-00P	Ungapped	25 %		2.19 mm²	0.156 in	3.96 mm	Parylene	0.101 in	2.57 mm	244 nH	28	Toroid	850		0.101 in	4.19 mm⁻¹	2.56 mm	9.16 mm
Laird Technologies EMI 28T0100-30P	Ungapped	20 %			0.1 in	2.54 mm	Parylene		1.02 mm	117 nH	28	Toroid	850		0.04 in	9.15 mm⁻¹		5.53 mm	0.6 mm²
Laird Technologies EMI 28T0231-10P	Ungapped	20 %	12.99 mm				Parylene	0.121 in		337 nH	28	Toroid	850			3.08 mm⁻¹	3.07 mm		4.22 mm²
Laird Technologies EMI 28T0119-00P	Ungapped	20 %	5.988 mm	1.06 mm²	0.12 in	3.05 mm	Parylene		1.27 mm	189 nH	28	Toroid	850		0.05 "	5.651 mm⁻¹				6.345 mmł	5.651 mm⁻ą	1.06 mm˛	6.345 mm³
Laird Technologies EMI 28T0122-00P	Ungapped	20 %			0.12 in	3.05 mm	Parylene	0.07 in	1.78 mm	172 nH	28	Toroid	850	6.938 mm		6.207 mm⁻¹			1.118 mm²				7.755 mm³
Laird Technologies EMI 28T0135-10P	Ungapped	20 %			0.136 in	3.45 mm	Parylene		2.08 mm	230 nH	28	Toroid	850	4.45 mm	0.082 "				1.7 mm²
Laird Technologies EMI 28T0119-10P	Ungapped	20 %	5.93 mm		0.121 in	3.07 mm	Parylene	0.031 in		113 nH	28	Toroid	850			8.77 mm⁻¹	0.79 mm							0.68 mm²
Laird Technologies EMI 28T0551-00G	Ungapped	20 %			0.554 in	14.07 mm	Epoxy		5.08 mm	375 nH	28	Toroid	850	34.91 mm	0.2 in	2.72 mm⁻¹								12.83 mm²
