500V RF MOSFET
Key Features
- Semi-Cap (6, 13, 27, 40 MHz)
- Industrial Glass (6, 13, 27, 40 MHz)
- PV Cells (6, 13, 27, 40 MHz)
- Flat Panel Displays (6, 13, 27, 40 MHz)
- Mass Spectrometry (13, 27 MHz)
- Dielectric Heating (2 to 40 MHz)
- Machine Tools (6, 13, 27 MHz)
- Drilling (6, 13, 27 MHz)
- Marking (13, 27, 40, 81, 108 MHz)
- Cutting (6, 13, 27 MHz)
- MRI (8 to 36, 64, 128 300 MHz)
- Laser Scalpel (13, 27, 40, 81, 108 MHz)
- Diathermy/Hyperthermia (8 MHz)
- Chemical Analysis (13, 27 MHz)
- Marine Radio (2 to 40 MHz)
- HF Radio (2 to 40 MHz)
- FM Broadcast (87 to 108 MHz)
Description
AI
The ARF family of RF power MOSFETs is optimized for applications requiring frequencies as high as 150 MHz and operating voltages as high as 400V. Historically, RF power MOSFETs were limited to applications of 50V or less. This limitation has been removed by combining Microchip’s high-voltage MOSFET technology with RF-specific die geometries.
