PNG.M0 Series
Manufacturer: LEMO
Beta
⌘K
CONN RCPT FMALE 7P GOLD SLDR CUP
| Part | Connector Type | Current Rating (Amps) | Primary Material | Shielding | Shell Material | Mounting Feature | Contact Finish - Mating | Fastening Type | Applications | Color | Ingress Protection | Insert Material | Number of Positions | Orientation | Operating Temperature [Min] | Operating Temperature [Max] | Shell Size - Insert |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LEMO | Receptacle Female Sockets | 5 A | Plastic | Unshielded | Polyetherimide (PEI) | Bulkhead - Rear Side Nut | Gold | Detent Lock Push-Pull | Automotive Industrial Medical Testing Equipment & Measurement | Gray | IP64 - Dust Tight Water Resistant | Polyetheretherketone (PEEK) | 7 | G | -50 °C | 170 °C | |
LEMO | Receptacle Female Sockets | 8 A | Plastic | Unshielded | Polyetherimide (PEI) | Bulkhead - Rear Side Nut | Gold | Detent Lock Push-Pull | Automotive Industrial Medical Testing Equipment & Measurement | Black Blue | IP64 - Dust Tight Water Resistant | Polyetheretherketone (PEEK) | 4 | G | -50 °C | 170 °C | M04 |
LEMO | Receptacle Female Sockets | 10 A | Plastic | Unshielded | Polyetherimide (PEI) | Bulkhead - Rear Side Nut | Gold | Detent Lock Push-Pull | Automotive Industrial Medical Testing Equipment & Measurement | Gray | IP64 - Dust Tight Water Resistant | Polyetheretherketone (PEEK) | 2 | G | -50 °C | 170 °C | M02 |
LEMO | Receptacle Female Sockets | 5 A | Plastic | Unshielded | Polyetherimide (PEI) | Bulkhead - Rear Side Nut | Gold | Detent Lock Push-Pull | Automotive Industrial Medical Testing Equipment & Measurement | Gray Yellow | IP64 - Dust Tight Water Resistant | Polyetheretherketone (PEEK) | 8 | G | -50 °C | 170 °C | M08 |
LEMO | Receptacle Female Sockets | 7 A | Plastic | Unshielded | Polysulfone (PSU) | Bulkhead - Rear Side Nut | Gold | Detent Lock Push-Pull | Automotive Industrial Medical Testing Equipment & Measurement | Black | IP64 - Dust Tight Water Resistant | Polyetheretherketone (PEEK) | G | -50 °C | 90 °C | M05 | |
LEMO | Receptacle Female Sockets | 3 A | Plastic | Unshielded | Polyetherimide (PEI) | Bulkhead - Rear Side Nut | Gold | Detent Lock Push-Pull | Automotive Industrial Medical Testing Equipment & Measurement | Gray | IP64 - Dust Tight Water Resistant | Polyetheretherketone (PEEK) | 9 | G | -50 °C | 170 °C | M09 |
 LEMO | Receptacle Female Sockets | 10 A | Plastic | Unshielded | Polysulfone (PSU) | Bulkhead - Rear Side Nut | Gold | Detent Lock Push-Pull | Automotive Industrial Medical Testing Equipment & Measurement | Blue Gray | IP64 - Dust Tight Water Resistant | Polyetheretherketone (PEEK) | 2 | G | -50 °C | 90 °C | M02 |
LEMO | Receptacle Female Sockets | 5 A | Plastic | Unshielded | Polysulfone (PSU) | Bulkhead - Rear Side Nut | Gold | Detent Lock Push-Pull | Automotive Industrial Medical Testing Equipment & Measurement | Gray | IP64 - Dust Tight Water Resistant | Polyetheretherketone (PEEK) | 8 | G | -50 °C | 90 °C | M08 |
LEMO | Receptacle Female Sockets | 6 A | Plastic | Unshielded | Polysulfone (PSU) | Bulkhead - Rear Side Nut | Gold | Detent Lock Push-Pull | Automotive Industrial Medical Testing Equipment & Measurement | Gray | IP64 - Dust Tight Water Resistant | Polyetheretherketone (PEEK) | 6 | G | -50 °C | 90 °C | M06 |
