333-064 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 64POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Contact Type | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Termination | Number of Rows [custom] | Contact Finish | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Read Out | Contact Material | Pitch | Pitch | Number of Positions/Bay/Row | Gender | Card Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Cantilever | Green | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Through Hole | Solder | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Cantilever | Green | Flush Mount M3 Threaded Insert Top Opening | Right Angle Through Hole | Wire Wrap | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Cantilever | Green | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Through Hole | Solder | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Cantilever | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Board Edge Straddle Mount | Solder | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge | Card Extender |
 EDAC Inc. | Polyester Thermoplastic | 2 | Cantilever | Green | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Through Hole | Solder | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Cantilever | Green | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Through Hole | Solder Eyelet(s) | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Cantilever | Green | 0.156 " | 3.96 mm | Through Hole | Solder | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Cantilever | Green | M3 Threaded Insert Top Mount Opening | Through Hole | Wire Wrap | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Cantilever | Green | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Right Angle Through Hole | Wire Wrap | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Cantilever | Green | Flush Mount M3 Threaded Insert Top Opening | Through Hole | Solder | 2 | Gold | 64 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Dual | Copper Alloy | 3.96 mm | 0.156 in | 32 | Female | Non Specified - Dual Edge |
