UCJ Series

Manufacturer: Nichicon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - SMD 10VOLTS 330UF AEC-Q200

Part	Voltage - Rated	Lifetime @ Temp.	Surface Mount Land Size [x]	Surface Mount Land Size [y]	Surface Mount Land Size [y]	Surface Mount Land Size [x]	Capacitance	Polarization	Package / Case	Ratings	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Ripple Current @ High Frequency	Ripple Current @ Low Frequency	Applications	ESR (Equivalent Series Resistance)	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [diameter]	Size / Dimension [diameter]	Tolerance	Mounting Type
Nichicon UCJ1A331MCL1GS	10 V	2000 Hrs	0.406 "	0.406 in	10.3 mm	10.3 mm	330 µF	Polar	Radial Can - SMD	AEC-Q200	0.413 "	10.5 mm	400 mA	200 mA	General Purpose	1.5 Ohm	125 °C	-40 C	0.394 in	10 mm	20 %	Surface Mount
Nichicon UCJ1V330MCL1GS	35 V	2000 Hrs	0.26 in	0.26 in	6.6 mm	6.6 mm	33 ÁF	Polar	Radial Can - SMD	AEC-Q200	0.354 in	9 mm	95 mA	47.5 mA	General Purpose	14 Ohm	125 °C	-40 C	0.248 "	6.3 mm	20 %	Surface Mount
Nichicon UCJ1H470MCL1GS	50 VDC	2000 Hrs	0.406 "	0.406 in	10.3 mm	10.3 mm	47 µF	Polar	Radial Can - SMD	AEC-Q200	0.413 "	10.5 mm	330 mA	165 mA	General Purpose	1.5 Ohm	125 °C	-40 C	0.394 in	10 mm	20 %	Surface Mount
Nichicon UCJ1A221MCL1GS	10 V	2000 Hrs	0.327 in	0.327 in	8.3 mm	8.3 mm	220 µF	Polar	Radial Can - SMD	AEC-Q200	0.413 "	10.5 mm	250 mA	125 mA	General Purpose	2 Ohms	125 °C	-40 C	0.315 in	8 mm	20 %	Surface Mount
Nichicon UCJ1V100MCL1GS	35 V	2000 Hrs	0.26 in	0.26 in	6.6 mm	6.6 mm	10 µF	Polar	Radial Can - SMD	AEC-Q200	0.354 in	9 mm	95 mA	47.5 mA	General Purpose	14 Ohm	125 °C	-40 C	0.248 "	6.3 mm	20 %	Surface Mount
