HIF3BAG Series

Catalog

CONN HEADER VERT 26POS 2.54MM

Part	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Number of Positions Loaded	Contact Shape	Number of Rows [custom]	Insulation Color	Overall Contact Length	Overall Contact Length	Number of Positions	Contact Length - Mating	Contact Length - Mating	Shrouding	Style	Insulation Height [z]	Insulation Height [z]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Insulation Material	Contact Finish - Mating	Material Flammability Rating	Fastening Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post	Contact Length - Post	Features	Termination	Mounting Type	Contact Type	Pitch - Mating	Pitch - Mating	Contact Material	Voltage Rating	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Post	Insulation Height	Insulation Height	Current Rating (Amps)
Hirose Electric Co Ltd HIF3BAG-26PA-2.54DSA(71)	78.7 µin	2 µm	All	Square	2	Black	16.7 mm	0.657 in	26	6 mm	0.236 in	Shrouded - 4 Wall	Board to Cable/Wire	0.701 in	17.8 mm	0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.13 "	3.3 mm	Keying Slot	Solder	Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin
Hirose Electric Co Ltd HIF3BAG-30PA-2.54DSA(71)	78.7 µin	2 µm	All	Square	2	Black	16.7 mm	0.657 in	30	6 mm	0.236 in	Shrouded - 4 Wall	Board to Cable/Wire	0.701 in	17.8 mm	0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.13 "	3.3 mm	Keying Slot	Solder	Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin
Hirose Electric Co Ltd HIF3BAG-10PA-2.54DSA(71)	78.7 µin	2 µm	All	Square	2	Black	16.7 mm	0.657 in	10	6 mm	0.236 in	Shrouded - 4 Wall	Board to Cable/Wire	0.701 in	17.8 mm	0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.13 "	3.3 mm		Solder	Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin
Hirose Electric Co Ltd HIF3BAG-10PA-2.54DS(63)	78.7 µin	2 µm	All	Square	2	Black			10			Shrouded - 4 Wall	Board to Cable/Wire			0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.118 in	3 mm		Solder	Right Angle Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin	0.335 "	8.51 mm	Varies by Wire Gauge
Hirose Electric Co Ltd HIF3BAG-16PA-2.54DSA(71)	78.7 µin	2 µm	All	Square	2	Black	16.7 mm	0.657 in	16	6 mm	0.236 in	Shrouded - 4 Wall	Board to Cable/Wire	0.701 in	17.8 mm	0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.13 "	3.3 mm	Keying Slot	Solder	Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin
Hirose Electric Co Ltd HIF3BAG-20PA-2.54DS(71)	78.7 µin	2 µm	All	Square	2	Black			20	6 mm	0.236 in	Shrouded - 4 Wall	Board to Cable/Wire			0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.118 in	3 mm		Solder	Right Angle Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin	0.335 "	8.51 mm
Hirose Electric Co Ltd HIF3BAG-20PA-2.54DSA(71)	78.7 µin	2 µm	All	Square	2	Black	16.7 mm	0.657 in	20	6 mm	0.236 in	Shrouded - 4 Wall	Board to Cable/Wire	0.701 in	17.8 mm	0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.13 "	3.3 mm	Keying Slot	Solder	Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin
Hirose Electric Co Ltd HIF3BAG-10PA-2.54DSA(63)	78.7 µin	2 µm	All	Square	2	Black			10			Shrouded - 4 Wall	Board to Cable/Wire	0.701 in	17.8 mm	0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.13 "	3.3 mm	Keying Slot	Solder	Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin			Varies by Wire Gauge
Hirose Electric Co Ltd HIF3BAG-40PA-2.54DS(63)	78.7 µin	2 µm	All	Square	2	Black			40			Shrouded - 4 Wall	Board to Cable/Wire			0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.118 in	3 mm		Solder	Right Angle Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin	0.335 "	8.51 mm	Varies by Wire Gauge
Hirose Electric Co Ltd HIF3BAG-16PA-2.54DSA(63)	78.7 µin	2 µm	All	Square	2	Black			16			Shrouded - 4 Wall	Board to Cable/Wire	0.701 in	17.8 mm	0.1 in	2.54 mm	Polybutylene Terephthalate (PBT)	Gold	UL94 V-0	Latch Lock/Eject Hooks	8 µin	0.203 µm	0.13 "	3.3 mm	Keying Slot	Solder	Through Hole	Male Pin	0.1 "	2.54 mm	Brass	200 V	Header	-55 C	85 °C	Tin			Varies by Wire Gauge
