BD9015 Series
Manufacturer: Rohm Semiconductor
Beta
⌘K
3.9 TO 30V, 2CH SYNCHRONOUS RECTIFICATION STEP-DOWN CONTROLLER
| Part | Control Features | Operating Temperature [Min] | Operating Temperature [Max] | Output Type | Package / Case | Mounting Type | Grade | Clock Sync | Topology | Function | Output Phases | Voltage - Supply (Vcc/Vdd) [Max] | Voltage - Supply (Vcc/Vdd) [Min] | Output Configuration | Number of Outputs | Qualification | Frequency - Switching [Min] | Frequency - Switching [Max] | Supplier Device Package | Synchronous Rectifier |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | Enable Frequency Control Power Good Soft Start | -40 °C | 105 °C | Transistor Driver | 48-LQFP | Surface Mount | Automotive | Buck | Step-Down | 1 | 30 V | 3.9 V | Positive | 2 | AEC-Q100 | 250 kHz | 550 kHz | 48-VQFPC (7x7) |
