HM42 Series

Catalog

PULSE XFMR 2:1:1 300UH

Part	Inductance	Operating Temperature [Max]	Operating Temperature [Min]	ET (Volt-Time)	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Mounting Type	Turns Ratio - Primary:Secondary [custom]	Turns Ratio - Primary:Secondary [custom]	Turns Ratio - Primary:Secondary [custom]	Transformer Type	Height - Seated (Max)	Turns Ratio - Primary:Secondary [custom]
TT Electronics/BI Magnetics HM42-10002LFTR	300 µH	125 °C	-40 C	40.4 VµS	0.319 "	6.6 mm	8.1 mm	0.26 in	0.217 "	5.5 mm	Surface Mount	1	1	2	Gate Drive
TT Electronics/BI Magnetics HM42-40004LFTR	1200 µH	125 °C	-40 C	45.4 VµS	0.346 "	9.2 mm	8.8 mm	0.362 in	0.307 in		Surface Mount	1	1	2	Gate Drive	7.8 mm
TT Electronics/BI Magnetics HM42-30001LFTR	980 µH	125 °C	-40 C	30.2 VµS	0.46 in	8.64 mm	11.68 mm	0.34 in	0.161 in	4.1 mm	Surface Mount		1	1	Gate Drive		1
