uvz Series

Manufacturer: Nichicon

Catalog

CAPACITOR: ELECTROLYTIC; THT; 10000UF; 10VDC; Ø16X35.5MM; ±20%

Part	Height - Seated (Max)	Height - Seated (Max) [Max] [z]	Voltage - Rated	Polarization	Applications	Capacitance	Tolerance	Package / Case	Mounting Type	Ripple Current @ High Frequency	Ripple Current @ Low Frequency	Lead Spacing	Lead Spacing	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [diameter]	Size / Dimension [diameter]	Lifetime @ Temp.	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Nichicon UVZ1A103MHD	37 mm	1.457 in	10 V	Polar	General Purpose	10000 µF	20 %	Can Radial	Through Hole	2.1735 A	1.89 A	0.295 in	7.5 mm	-55 C	105 ░C	0.63 in	16 mm	2000 Hrs
Nichicon UVZ1A102MPD			10 V	Polar	General Purpose	1000 µF	20 %	Can Radial	Through Hole	529 mA	460 mA	0.197 "	5 mm	-55 C	105 ░C	0.394 in	10 mm	2000 Hrs	0.492 in	12.5 mm
Nichicon UVZ1A682MHD			10 V	Polar	General Purpose	6800 µF	20 %	Can Radial	Through Hole	1.8055 A	1.57 A	0.295 in	7.5 mm	-55 C	105 ░C	0.63 in	16 mm	2000 Hrs	27 mm		1.063 in
