396-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 14POS 0.125
| Part | Termination Rows | Material - Insulation | Gender | Read Out | Contact Material | Termination | Card Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Contact Type | Number of Positions/Bay/Row | Number of Rows | Color | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Single | Copper Alloy | Solder Wire Wrap | Non Specified - Single Edge | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | -40 C | 105 ░C | 14 | Right Angle Through Hole | 0.25 Ám | 10 Áin | Gold | Cantilever | 14 | 1 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | |||
 EDAC Inc. | Polyester Thermoplastic | Female | Dual | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | -40 C | 105 ░C | 14 | Through Hole | 0.25 Ám | 10 Áin | Gold | Cantilever | 7 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 2 | 2 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Single | Copper Alloy | Solder Wire Wrap | Non Specified - Single Edge | 4-40 Threaded Insert Top Mount Opening | -40 C | 105 ░C | 14 | Right Angle Through Hole | 0.25 Ám | 10 Áin | Gold | Cantilever | 14 | 1 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | |||||
 EDAC Inc. | Polyester Thermoplastic | Female | Dual | Copper Alloy | Solder | Non Specified - Dual Edge | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | -40 C | 105 ░C | 14 | Through Hole | 0.25 Ám | 10 Áin | Gold | Cantilever | 7 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 2 | 2 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Single | Copper Alloy | Wire Wrap | Non Specified - Single Edge | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | -40 C | 105 ░C | 14 | Through Hole | 0.25 Ám | 10 Áin | Gold | Cantilever | 14 | 1 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | |||
 EDAC Inc. | Polyester Thermoplastic | Female | Dual | Copper Alloy | Solder | Non Specified - Dual Edge | 0.156 " | 3.96 mm | -40 C | 105 ░C | 14 | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Gold | Cantilever | 7 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 2 | 2 | Card Extender | |||
 EDAC Inc. | Polyester Thermoplastic | Female | Dual | Copper Alloy | Solder | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | -40 C | 105 ░C | 14 | Through Hole | 0.25 Ám | 10 Áin | Gold | Cantilever | 7 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 2 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | Female | Dual | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | -40 C | 105 ░C | 14 | Through Hole | 0.25 Ám | 10 Áin | Gold | Cantilever | 7 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 2 | 2 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Single | Copper Alloy | Solder Wire Wrap | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | -40 C | 105 ░C | 14 | Right Angle Through Hole | 0.25 Ám | 10 Áin | Gold | Cantilever | 14 | 1 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | Single | Copper Alloy | Solder | Non Specified - Single Edge | 4-40 Threaded Insert Top Mount Opening | -40 C | 105 ░C | 14 | Through Hole | 0.25 Ám | 10 Áin | Gold | Cantilever | 14 | 1 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in |
