896-023 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 23POS 0.125
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Termination | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Pitch | Pitch | Card Type | Gender | Contact Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Color | Read Out | Number of Rows | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Right Angle Through Hole |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Through Hole |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Right Angle Through Hole | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Solder Eyelet(s) | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Through Hole |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Wire Wrap | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Through Hole |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Wire Wrap | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Through Hole | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Solder Eyelet(s) | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Through Hole | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Right Angle Through Hole |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Wire Wrap | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Through Hole |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 23 | 125 °C | -40 C | Gold | Solder | Copper Alloy | 0.25 Ám | 10 Áin | 23 | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Cantilever | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Single | 1 | Right Angle Through Hole |
