C2040A Series

Catalog

HOOK-UP STRND 20AWG GRN 1000'

Part	Length	Length	Jacket Color	Cable Type	Conductor Strand [custom]	Conductor Strand [custom]	Wire Gauge	Conductor Material	Operating Temperature [Min]	Operating Temperature [Max]	Ratings	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]
Prysmian Group C2040A.21.06	304.8 m	1000 ft	Green	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "
Prysmian Group C2040A.12.04			Orange	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "	100 ft	30.5 m
Prysmian Group C2040A.12.03			Red	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "	100 ft	30.5 m
Prysmian Group C2040A.21.03	304.8 m	1000 ft	Red	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "
Prysmian Group C2040A.12.04			Orange	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "	100 ft	30.5 m
Prysmian Group C2040A.12.02			White	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "	100 ft	30.5 m
Prysmian Group C2040A.21.04	304.8 m	1000 ft	Orange	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "
Prysmian Group C2040A.21.03	304.8 m	1000 ft	Red	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "
Prysmian Group C2040A.12.07			Blue	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "	100 ft	30.5 m
Prysmian Group C2040A.21.01	304.8 m	1000 ft	Black	Hook-Up	10	30 AWG	20 AWG	Copper Annealed Tinned	-20 ░C	105 ░C	ASTM B-33 UL Style 1007/1569	Poly-Vinyl Chloride (PVC)	0.41 mm	0.016 in	300 VDC	1.78 mm	0.07 "
